PCF8575CDBE4
| Manufacturer | |
| Description | PCF8575CDB & DBR SETUP IC I/O EXPANDER I2C 16B 24SSOP Interface - I/O Expanders Remote 16-Bit I2C & SMBus I/O Expander PCF8575CDBE4 IC, 16BIT I2C/SMBUS EXPANDER, 8575 Remote 16-Bit I2C and SMBus I/O Expander with Interrupt Output |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Interface - I/O Expanders | Standard Package | 60 |
| Factory Pack Quantity | 60 | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85411000 | Part Status | :8575 |
Electrical
| Frequency | :400kHz | Interface | I²C, SMBus |
| Logic Type | PCF8575C | Output Type | Open Drain |
| Number of I/O | 16 | Number of Bits | :16 |
| Clock Frequency | 400kHz | Frequency - Max | 400 kHz |
| Current - Output | :10µA | Interrupt Output | Yes |
| Voltage - Supply | 4.5 V ~ 5.5 V | Sampling Frequency | 0.4 |
| Current Rating (Max) | Catalog | Current - Output Source/Sink | 10mA, 25mA |
Mechanical
| Weight | 0.006081 oz | Packaging | Tube |
| Termination | :SMD | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :24 |
| Package / Case | 24-SSOP (0.209", 5.30mm Width) | Material Finish | :- |
| Package Quantity | 60 | TUBE | Number of Positions | :8575 |
| Supplier Device Package | 24-SSOP | ||
Product Info
| Series | PCF8575C | Features | POR |
| Software | SCPS123F | Base Unit | :8575 |
| Communications | :I/O Expander | Control Interface | :I2C, Parallel |
| Functional Diagram | alt_scps123f.gif | Utilized IC / Part | View |
| Other Specifications | :16bit | Number of Inputs and Type | 16 |
Environmental
| Temperature - Test | -40 to 85 | Operating Temperature | -40°C ~ 85°C |
