OPA847ID
| Manufacturer | |
| Description | OP Amp Single Volt Fdbk ±6V 8-Pin SOIC Tube IC OPAMP VFB 3.9GHZ 8SOIC OPA847ID, Operational Amplifier Voltage Feedback, 3900MHz, 8-Pin SOIC High Speed Operational Amplifiers Wdebnd Ult-Lo Noise Voltage Feedback OP Amp Single Volt Fdbk �6V/12V 8-Pin SOIC Tube IC, OP-AMP, 3.9GHZ, 950V/ us, SOIC-8 Wideband, Ultra-Low Noise,Voltage Feedback Operational Amplifier with Shutdown Texas Instruments 运算放大器, 3900MHz, 8针 SOIC |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Voltage Feedback Amplifier | Other Names | 296-15171-5 |
| Product Category | High Speed Operational Amplifiers | Standard Package | Rail / Tube |
| Factory Pack Quantity | 75 | Standard Package Name | SOIC |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85423300 | Part Status | ACTIVE |
| Rad Hardened | No | ||
Electrical
| Gain | 98 dB | PSRR | 95 dB |
| Slew Rate | 950@±5V V/us | Output Type | No |
| Power - Input | Dual | Settling Time | 20 ns |
| Vn at Flatband | 0.85 | Transistor Type | :Voltage Feedback |
| CMRR, PSRR (Typ) | 95 dB | Current - Output | 18.1mA |
| Voltage - Supply | 5 V ~ 12 V, ±2.5 V ~ 6 V | Power Supply Type | Dual |
| Number of Channels | 1 | Number of Elements | 1 |
| Current - Input Bias | 19µA | Current Rating (Max) | Catalog |
| Offset Voltage Drift | 1.5 | Number of ADCs / DACs | :1 |
| Voltage - Input (Min) | 100µV | Gain Bandwidth Product | 3900 MHz |
| Rail-to-Rail Operation | No | Current - Quiescent (Iq) | 18.9 |
| Current - Input Bias (Max) | 39@±5V uA | Current - Output / Channel | 100mA |
| Input Offset Current (Max) | 0.6@±5V | Voltage - Supply (Vcc/Vdd) | 12 |
| Input Noise Current Density | 2.5@±5V pA/rtHz | Input Noise Voltage Density | 0.85@±5V nV/rtHz |
| Voltage - Supply Span (Typ) | �5 V | Voltage - Input Offset (Max) | 0.5@±5V mV |
| Voltage - Output Difference (Typ) @ Distance | 98 dB | ||
Mechanical
| Width | 4(Max) | Weight | 0.002677 oz |
| Bandwidth | :3.9GHz | Packaging | Tube |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :8 |
| Package / Case | 8SOIC | Package Cooled | SOIC |
| Length - Overall | 5(Max) | Package Quantity | SOIC |
| Number of Positions | 8 | Shell Size - Insert | 1.5(Max) |
| Supplier Device Package | 8-SOIC | ||
Product Info
| Type | Voltage Feedback Amplifier | Series | OPA847 |
| Shutdown | No | Software | SBOS251E |
| Technology | Bipolar | Architecture | Voltage Feedback |
| Manufacturer | High Speed Amplifier | Amplifier Type | Voltage Feedback |
| Pattern Number | Y | Number of Circuits | 1 |
| Utilized IC / Part | View | Printed Circuit Board | 8 |
Environmental
| Temperature - Test | -40 to 85 | Operating Temperature | -40 to 85 °C |
