OPA549T
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Operational Amplifiers - Op Amps | Standard Package | Rail / Tube |
| Factory Pack Quantity | 25 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85423300 | Part Status | ACTIVE |
| Rad Hardened | No | ||
Electrical
| Gain | 110 dB | PSRR | 92.04 dB |
| Slew Rate | 9@±30V V/us | Vn at 1kHz | 70 |
| Output Type | No | Offset Drift | 20 |
| Power - Input | Single/Dual | Rise Time (Typ) | 9V/μs |
| Transistor Type | :High Voltage | CMRR, PSRR (Typ) | 80 dB |
| Current - Output | 26mA | Voltage - Supply | 8 V |
| Number of Channels | 1 | Number of Elements | 1 |
| Current - Input Bias | 100nA | Current Rating (Max) | Catalog |
| Number of ADCs / DACs | :1 | Voltage - Input (Min) | 1mV |
| Gain Bandwidth Product | 0.9 MHz | Current - Quiescent (Iq) | 35 |
| Current - Input Bias (Max) | 0.5@±30V uA | Current - Output / Channel | 10A |
| Voltage - Supply (Vcc/Vdd) | 60 | Vos (Offset Voltage @ 25C) | 5 |
| Input Noise Current Density | 1@±30V pA/rtHz | Input Noise Voltage Density | 70@±30V nV/rtHz |
| Voltage - Supply Span (Typ) | �5/�9/�12/�15 V | Frequency Bands (Low / High) | 900kHz |
| Voltage - Input Offset (Max) | 5@±30V mV | Voltage - Output Difference (Typ) @ Distance | 110 dB |
Mechanical
| Weight | 0.002 | Bandwidth | :900kHz |
| Packaging | Tube | Mounting Type | Through Hole |
| Mounting Style | Through Hole | Number of Pins | :11 |
| Package / Case | 11TO-220 | Package Cooled | TO-220 |
| Material Finish | :- | Package Quantity | 25 |
| Number of Positions | 11 +Tab | Supplier Device Package | TO-220-11 |
Product Info
| Spg | 25 | Type | General Purpose Amplifier |
| Series | OPA549 | DELETED | Compliant |
| Shutdown | Yes | Software | SBOS093E |
| Amplifier Type | Power | Pattern Number | Y |
| Number of Units | 1 | Number of Circuits | 1 |
| Utilized IC / Part | View | ||
Environmental
| Temperature - Test | -40 to 85 | Operating Temperature | -40 to 85 °C |
Documents & Media
PDF Document
Online Document
PDF Document
Online Document
Online Document
