MSP430F5500IRGZT
| Manufacturer | |
| Description | MCU 16-bit MSP430 RISC 8KB Flash 2.5V/3.3V 48-Pin VQFN EP T/R IC MCU 16BIT 8KB FLASH 48VQFN 16-bit Microcontrollers - MCU Mixed Signal MCU IC, 16BIT MCU, MSP430F5, 25MHZ, 48-VQFN Mixed Signal Microcontroller |
| Category |
Business
| Tradename | MSP430 | Product Category | 16-bit Microcontrollers - MCU |
| Standard Package | Tape & Reel | Factory Pack Quantity | 250 |
| Standard Package Name | QFN | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85423190 | Part Status | ACTIVE |
| Approval Agency | No | Security Features | N/A |
Electrical
| GPIO | 31 | Speed | 25 MHz |
| Memory | 3 | RAM Size | 6 KB |
| Core Size | 16-Bit | Core Type | RISC |
| Frequency | 25 | Interface | I2C/SPI/UART |
| Clock Rate | 25 MHz | Comparator | 4 |
| Delay Time | 5 | Memory Size | 4 KB |
| Number of I/O | 31 | Counter/Timers | 4 |
| Voltage Rating | 1.8 | Watchdog Timer | 1 |
| Clock Frequency | :25MHz | Oscillator Type | Internal |
| Serial Protocol | 1 | Voltage - Supply | 2.5|3.3 V |
| Analog Input:Output | Slope | Non-Volatile Memory | 8 |
| Program Memory Size | 8 KB | Program Memory Type | Flash |
| Number of Conductors | :1 | Voltage - Input (Min) | 3.6 |
| Voltage - Supply (Min) | 3.6 | Power - Average Forward | 2.5 |
| Voltage - Supply (Vcc/Vdd) | 1.8 V ~ 3.6 V | ||
Mechanical
| Width | 7.15(Max) | Weight | 0 |
| Packaging | Tape & Reel (TR) | Lead Style | No Lead |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :48 | Package / Case | 48VQFN EP |
| Length - Overall | 7.15(Max) | Package Quantity | VQFN EP |
| Number of Positions | 48 | Shell Size - Insert | 0.95(Max) |
| Number of Cores/Bus Width | 16 Bit | ||
Product Info
| SPI | 2 | Series | Series 5 |
| Features | USB Real-Time Clock Watchdog Brown Out Reset IrDA | Protocol | 1 |
| Software | SLAS645J | Bootloader | USB |
| Multiplier | 32x32 | On-Chip RAM | No |
| Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT | Special I/O | N/A |
| Architecture | RISC | Connectivity | I²C, IrDA, LIN, SCI, SPI, UART/USART, USB |
| Number of Timers | 18 | Controller Series | :MSP430 |
| Functional Diagram | fbd_slas645j.gif | RF Family/Standard | MSP430 |
| Utilized IC / Part | View | DigiKey Programmable | Yes |
| Printed Circuit Board | 48 | ||
Environmental
| Temperature - Test | -40 to 85 | Operating Temperature | -40 to 85 °C |
