LP55281TL/NOPB
| Manufacturer | |
| Description | LED DRVR 12Segment 3.3V/5V 36-Pin uSMD T/R LED Lighting Drivers IC LED DRIVER RGB 36-USMD Quad RGB Driver LED Lighting Drivers Quad RGB Driver 36-DSBGA -30 to 85 |
| Category |
Business
| Standard Package | Tape & Reel | Factory Pack Quantity | 250 |
Compliance
| RoHS | RoHS Compliant | Part Status | ACTIVE |
Electrical
| LED | 13 | Channels | 12 |
| Frequency | 2 MHz | Efficiency | 88 |
| Output Type | Current Mode | Voltage Rating | 3 V to 5.5 V |
| Current - Output | 300 mA | Current - Supply | 0.6 mA |
| Voltage - Supply | 2.7 to 5.5 V | Number of Outputs | 12 |
| Current Rating (Max) | Catalog | Voltage - Input (Min) | 4 V ~ 5.3 V |
| Current - Output / Channel | 40 | Current - Output High, Low | 40000 uA |
| Constant Current Load - Max | Yes | Current - Average Rectified (Io) | Yes |
Mechanical
| Height | 0.36 mm | Length | 3 mm |
| LED Color | Parallel | Packaging | Reel |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Package / Case | 36uSMD | Package Quantity | 250 | SMALL T&R |
| Primary Material | Light Management Unit (LMU) | Supplier Device Package | 36-uSMD |
Product Info
| Type | Color, RGB | Series | LP55281 |
| Features | I2C Control | Software | SNVS458C |
| Topology | PWM, Step-Up (Boost) | Manufacturer | Texas Instruments |
| Functional Diagram | fbd_snvs458c.gif | Internal Switch(s) | Yes |
| Number of Segments | 12 | Utilized IC / Part | View |
| Internal Connection | Yes | Output Configuration | Surface Mount |
Environmental
| Mechanical Life | New At Mouser | Temperature - Test | -30 to 85 |
| Operating Temperature | + 85 C | ||
