LM94022QBIMG/NOPB
| Manufacturer | |
| Description | Temp Sensor Analog(Voltage) 5-Pin SC-70 T/R IC TEMP SENS 1.5V AB OUT SC70-5 LM94022QBIMG/NOPB, Temperature & Humidity Sensor ±1.5 to ±2.7°C 1.5 to 5.5V 5-Pin SC-70 Board Mount Temperature Sensors 1.5V SC70 Multi-Gain Analog Temp Sensor TEMP SENSOR, +/-2.7 DEG C, SC-70-5 Automotive Grade, ±1.5°C Temperature Sensor with Multiple Gain and Class-AB Analog Output Texas Instruments 温度传感器, ±1.5 → ±2.7°C, 模拟接口, 5针 SC-70封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Tape & Reel | Factory Pack Quantity | 1000 |
| Standard Package Name | SOT-323 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| EU RoHS | Compliant | Tariff No | 90251920 |
| Part Status | ACTIVE | ||
Electrical
| Gain | - 5.5 mV/C, - 8.2 mV/C, - 10.9 mV/C, -13.6 mV/C | Accuracy | ±2.7(Max) °C |
| Interface | Analog Output | Output Type | Analog(Voltage) |
| Sensor Type | :SC-70 | Voltage Rating | 1.5 |
| Current - Output | 7 mA | Voltage - Supply | 1.5 to 5.5 V |
| Current Rating (Max) | Automotive | Voltage - Supply (Min) | 5.5 |
| Current Transfer Ratio (Min) | -13.6 mV/°C | ||
Mechanical
| Width | 1.4(Max) | Weight | 0.000033 |
| Packaging | Tape and Reel | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Contact Timing | :± 2.7°C |
| Mounting Style | SMD/SMT | Number of Pins | :5 |
| Package / Case | 5SC-70 | Material Finish | :MSL 1 - Unlimited |
| Length - Overall | 2.15(Max) | Package Quantity | SC-70 |
| Number of Positions | 5 | Shell Size - Insert | 1(Max) |
| Supplier Device Package | SC-70-5 | ||
Product Info
| Series | LM94022-Q1 | Features | Selectable gain setting |
| Function | Temp Sensor | Shutdown | Yes |
| Software | SNIS140E | Configuration | Local |
| Functional Diagram | alt_snis140e.gif | Utilized IC / Part | View |
| Printed Circuit Board | 5 | ||
Environmental
| Temperature - Test | -50 to 150 | Sensing Temperature | -50°C ~ 150°C |
| Operating Temperature | - 50 C | Sensing Temperature - Local | :-50°C |
| Temperature Coefficient (Typ) | 1.5 | ||
