LM86CIMX/NOPB
| Manufacturer | |
| Description | Temp Sensor Digital Serial (2-Wire) 8-Pin SOIC N T/R IC TEMP SENSOR DGTL 8-SOIC Board Mount Temperature Sensors ?0.75?C Accurate, Remote Diode and Local Digital Temperature Sensor with Two-Wire Interface 8-SOIC 0 to 125 ±0.75°C Remote and Local Temperature Sensor with SMBus Interface |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | LM86CIMX/NOPBDKR | Standard Package | Tape & Reel |
| Factory Pack Quantity | 2500 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Part Status | ACTIVE |
Electrical
| Accuracy | ±1/±3(Max) °C | Interface | Serial (2-Wire) |
| Tolerance | ±1°C Local(Max), ±3°C Remote(Max) | Output Fan | Yes |
| Resolution | 8/10+Sign Bit | Output Type | Digital |
| Sensor Type | Internal and External | Number of Bits | 11 |
| Current - Output | 10 uA | Voltage - Supply | 3 to 3.6 V |
| Current Rating (Max) | Catalog | ||
Mechanical
| Packaging | Tape & Reel (TR) | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 8SOIC N |
| Package Quantity | 2500 | LARGE T&R | Supplier Device Package | 8-SOIC |
Product Info
| Series | LM86 | Function | Temp Sensor |
| Shutdown | Yes | Software | SNIS114E |
| Topology | ADC (Sigma Delta), Comparator, Register Bank | Output Alarm | Yes |
| Configuration | Local, Remote | Remote Capability | 1 |
| Functional Diagram | fbd_snis114e.gif | Utilized IC / Part | View |
Environmental
| Temperature - Test | 0 to 125 | Sensing Temperature | 0°C ~ 125°C |
| Operating Temperature | 0°C ~ 85°C | Temperature Coefficient | 0°C ~ 125°C |
| Temperature Coefficient (Typ) | 3 | ||
