LM86CIM/NOPB
| Manufacturer | |
| Description | Temp Sensor Digital Serial (2-Wire) 8-Pin SOIC N Rail Temp Sensor Digital Serial (2-Wire) 8-Pin SOIC Rail IC TEMP SENSOR DGTL 8-SOIC LM86CIM, 11bit Temperature Sensor ±1, ±3°C Serial-2 Wire 3.3V 8-Pin SOIC Board Mount Temperature Sensors ?0.75?C Accurate, Remote Diode and Local Digital Temperature Sensor with Two-Wire Interface 8-SOIC 0 to 125 ±0.75°C Remote and Local Temperature Sensor with SMBus Interface |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | LM86CIMNOPB | Standard Package | Rail / Tube |
| Factory Pack Quantity | 95 | Standard Package Name | SOIC |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Part Status | ACTIVE | ||
Electrical
| Accuracy | ±1/±3(Max) °C | Interface | Serial (2-Wire) |
| Tolerance | ±1°C Local(Max), ±3°C Remote(Max) | Output Fan | Yes |
| Resolution | 8/10+Sign Bit | Output Type | Digital |
| Sensor Type | Internal and External | Number of Bits | 11 |
| Voltage Rating | 3 V | Current - Output | 10 uA |
| Voltage - Supply | 3 to 3.6 V | Current Rating (Max) | Catalog |
| Voltage - Supply (Min) | 3.6 V | ||
Mechanical
| Width | 3.9mm | Height | 1.45mm |
| Length | 4.9mm | Packaging | Rail |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 8SOIC N |
| Package Cooled | SOIC N | Length - Overall | 5(Max) |
| Package Quantity | SOIC | Size / Dimension | 4.9 x 3.9 x 1.45mm |
| Number of Positions | 8 | Shell Size - Insert | 1.5(Max) |
| Supplier Device Package | 8-SOIC | ||
Product Info
| Series | LM86 | Function | Temp Sensor |
| Shutdown | Yes | Software | SNIS114E |
| Topology | ADC (Sigma Delta), Comparator, Register Bank | Output Alarm | Yes |
| Configuration | Local, Remote | Remote Capability | 1 |
| Functional Diagram | fbd_snis114e.gif | Utilized IC / Part | View |
| Printed Circuit Board | 8 | ||
Environmental
| Temperature - Test | 0 to 125 | Sensing Temperature | 0°C ~ 125°C |
| Operating Temperature | 0°C ~ 85°C | Temperature Coefficient | 0°C ~ 125°C |
| Temperature Coefficient (Typ) | 3 | ||
