LM324NE3
| Manufacturer | |
| Description | OP Amp Quad GP ±16V/32V 14-Pin PDIP Tube IC OPAMP GP 1.2MHZ 14DIP Operational Amplifiers - Op Amps Quad Op Amp OP Amp Quad GP ?16V/32V 14-Pin PDIP Tube IC, OP AMP, GP, 1.2MHZ, QUAD, 14DIP Quadruple Operational Amplifier Operational Amplifier Quad 1.2 MHz DIL-14, LM324, LM324NE3, Texas Instruments |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 296-27903-5 | Product Category | Operational Amplifiers - Op Amps |
| Standard Package | Rail / Tube | Factory Pack Quantity | 25 |
| Standard Package Name | PDIP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| EU RoHS | Compliant | Tariff No | 85423990 |
| Part Status | ACTIVE | Rad Hardened | No |
Electrical
| Gain | 100 dB | Slew Rate | 0.5@±15V V/us |
| Vn at 1kHz | 35 | Output Type | No |
| Power - Input | Single/Dual | Transistor Type | :High Gain |
| CMRR, PSRR (Typ) | 65 dB | Current - Output | 1.4mA |
| Voltage - Supply | 3 V | Power Supply Type | Single|Dual |
| Number of Channels | 4 | Number of Elements | 4 |
| Current - Input Bias | 20nA | Current Rating (Max) | Catalog |
| Number of ADCs / DACs | :4 | Voltage - Input (Min) | 3mV |
| Gain Bandwidth Product | 1.2 MHz | Rail-to-Rail Operation | No |
| Current - Quiescent (Iq) | 0.3 | Current - Input Bias (Max) | 0.25@5V uA |
| Current - Output / Channel | 60mA | Input Offset Current (Max) | 0.05@5V |
| Voltage - Supply (Vcc/Vdd) | 32 | Vos (Offset Voltage @ 25C) | 7 |
| Input Noise Voltage Density | 35@±15V nV/rtHz | Voltage - Input Offset (Max) | 7@30V mV |
| Voltage - Output Difference (Typ) @ Distance | 100 dB | ||
Mechanical
| Width | 6.6(Max) | Weight | 0.00027 |
| Bandwidth | :1.2MHz | Packaging | Tube |
| Lead Style | Through Hole | Mounting Type | Through Hole |
| Mounting Style | Through Hole | Number of Pins | :14 |
| Package / Case | 14PDIP | Package Cooled | PDIP |
| Material Finish | :- | Length - Overall | 19.69(Max) |
| Package Quantity | PDIP | Number of Positions | 14 |
| Shell Size - Insert | 5.08(Max) - 0.51(Min) | Supplier Device Package | 14-PDIP |
Product Info
| Type | General Purpose Amplifier | Series | LM324 |
| DELETED | Compliant | Shutdown | No |
| Software | SLOS066W | Base Unit | :324 |
| Technology | Bipolar | Manufacturer | High Gain Amplifier |
| Amplifier Type | General Purpose | Pattern Number | Y |
| Functional Diagram | fbd_slos066w.gif | Number of Circuits | 4 |
| Utilized IC / Part | View | Printed Circuit Board | 14 |
Environmental
| Temperature - Test | 0 to 70 | Operating Temperature | 0 to 70 °C |
