LM239ADR
| Manufacturer | |
| Description | Comparator Quad ±15V/30V 14-Pin SOIC T/R Comparator ICs Quad GP Differential IC QUAD DIFF COMPARATOR 14-SOIC Comparator Quad �15V/30V 14-Pin SOIC T/R IC, DIFFERENTIAL COMP, QUAD 0.3 uS SOIC14 Quad Differential Comparator Comparator Quad SOIC-14, LM239, LM239ADR, Texas Instruments 4通道 比较器, 开路集电极输出, 1.3μs, 多种电源电压适用, 14引脚 SOIC封装 Analog Comparators Quad GP Differential |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Analog Comparators | Other Names | 296-6618-2 |
| Product Category | Comparator ICs | Standard Package | Tape & Reel |
| Factory Pack Quantity | 2500 | Standard Package Name | SOIC |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85423990 | Part Status | ACTIVE |
| Rad Hardened | No | ||
Electrical
| Gain | 106.02 dB | Output Type | Open Collector |
| Power - Input | Single/Dual | Response Time | 1.3 us |
| Comparator Type | :Differential | Current - Output | 2 mA |
| Current - Supply | 0.5 mA | Voltage - Supply | 2 V |
| Power Supply Type | Single|Dual | Number of Channels | 4 |
| Number of Elements | 4 | Voltage - Threshold | 3 mV |
| Current - Input Bias | 50 | Current Rating (Max) | Catalog |
| Voltage - Input (Min) | 3 mV | Current - Output (Typ) | 6 mA |
| Rail-to-Rail Operation | No | Current - Quiescent (Iq) | 0.5 |
| Current - Quiescent (Max) | 2mA | Current - Input Bias (Max) | 0.25µA @ 5V |
| Voltage - Supply (Vcc/Vdd) | 36 | Vos (Offset Voltage @ 25C) | 3 |
| Voltage - Supply Span (Typ) | �3/�5/�9/�12 V | Voltage - Input Offset (Max) | 3 mV |
| Voltage - Output Difference (Typ) @ Distance | 106.02 dB | ||
Mechanical
| Width | 4(Max) | Weight | 0.004318 oz |
| Max Load | 0 | Packaging | Reel |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :14 |
| Package / Case | 14SOIC | Package Cooled | SOIC |
| Length - Overall | 8.75(Max) | Package Quantity | SOIC |
| Number of Positions | 14 | Shell Size - Insert | 1.5(Max) |
| Supplier Device Package | 14-SOIC | ||
Product Info
| Type | Differential | Series | LM239A |
| DELETED | Compliant | Software | SLCS006T |
| Technology | Bipolar | Manufacturer | Differential Comparator |
| Functional Diagram | fbd_slcs006t.gif | Utilized IC / Part | View |
| Output Configuration | :CMOS, MOS, TTL | Number of Comparators | :4 |
| Printed Circuit Board | 14 | ||
Environmental
| Switching Cycles | 1.3 | Temperature - Test | -25 to 85 |
| Operating Temperature | -25 to 125 °C | ||
