INA114BU
| Manufacturer | |
| Description | SP Amp INSTR Amp Single ±18V 16-Pin SOIC Tube IC OPAMP INSTR 1MHZ 16SOIC INA114BU, Instrumention Amplifier, 115dB CMRR, 16-Pin SOIC Instrumentation Amplifiers Precision Instrumentation Amp AMP INSTRUMENTATION, 16WSOIC, 114 Precision Instrumentation Amplifier Texas Instruments 仪表放大器, 50μV偏置, 1MHz, 115dB CMRR 16针 SOIC封装 |
| Category |
Business
| Product Category | Instrumentation Amplifiers | Standard Package | Rail / Tube |
| Factory Pack Quantity | 40 | Standard Package Name | SOIC |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423300 |
| Part Status | ACTIVE | ||
Electrical
| Gain | 80 dB | Output | :Single Ended |
| Slew Rate | 0.6 V/µs | Offset Drift | 5/G |
| CMRR, PSRR (Typ) | 115dB | Current - Output | 2.2mA |
| Current - Supply | 3 mA | Voltage - Supply | ±2.25 V |
| Power Supply Type | Dual | Number of Channels | 1 |
| Number of Elements | 3 | Resistance - Input | 10GΩ |
| Non-Volatile Memory | 0.002 | Current - Input Bias | 500pA |
| Current Rating (Max) | Catalog | Noise - 10Hz to 10kHz | 11 |
| Number of ADCs / DACs | :1 | Voltage - Input (Min) | 80(Typ) dB |
| Gain Bandwidth Product | 1 MHz | Rail-to-Rail Operation | No |
| Current - Quiescent (Iq) | 2.2 | Current - Input Bias (Max) | 0.002@±15V |
| Current - Output / Channel | 20mA | Voltage - Supply (Vcc/Vdd) | 36 |
| Voltage - Input Offset (Max) | 50 | ||
Mechanical
| Width | 7.52mm | Height | 2.35mm |
| Length | 10.28mm | Weight | 0.014829 oz |
| Bandwidth | :1MHz | Packaging | Tube |
| Lead Style | Gull-wing | Termination | :SMD |
| Mounting Type | Surface Mount | -3db Bandwidth | 1MHz |
| Mounting Style | SMD/SMT | Number of Pins | :16 |
| Package / Case | 16SOIC | Package Cooled | SOIC |
| Material Finish | :MSL 3 - 168 hours | Length - Overall | 10.5(Max) |
| Package Quantity | SOIC | Size / Dimension | 10.28 x 7.52 x 2.35mm |
| Number of Positions | 16 | Shell Size - Insert | 2.35(Max) |
| Supplier Device Package | 16-SOIC | ||
Product Info
| Type | Instrumentation Amplifier | Series | INA114 |
| Software | SBOS014 | Base Unit | :114 |
| Amplifier Type | Instrumentation | Number of Circuits | 1 |
| Utilized IC / Part | View | Other Specifications | :0.25µV/°C |
| Printed Circuit Board | 16 | Programmable Features | :10000 |
Environmental
| Operating Temperature | -40 to 85 °C | ||
