CD74HCT541M
| Manufacturer | |
| Description | Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin SOIC Tube Buffers & Line Drivers Tri-St N-Invrt Octal IC BUFF/DVR TRI-ST 8BIT 20SOIC CD74HCT541M, 8-Bit Buffer, Line Driver, HCT, 3-State Non-Inverting 5V 20-Pin SOIC IC, SM, LOGIC, 74HCT, BUFFER IC: digital; 3-state, line driver, octal buffer; SO20; 4.5÷5.5VDC High Speed CMOS Logic Octal Non-Inverting Buffers and Line Drivers with 3-State Outputs HCT, 8-Bit 三态 非反相 缓冲器，线路驱动器, 20针 SOIC封装 |
| Category |
Business
| Product Category | Buffers & Line Drivers | Standard Package | Bulk, Rail / Tube |
| Factory Pack Quantity | 25 | Standard Package Name | SOIC |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85411000 |
| Part Status | :74HCT541 | Rad Hardened | No |
Electrical
| Voltage | 5 | Input Type | Single Ended |
| Logic Type | HCT | Output Type | 3-State |
| Input Signal | Single-Ended | Number of Bits | 8 |
| Voltage Rating | 4.5 V | Number of Inputs | 8 |
| Voltage - Supply | 5.5 V | Number of Outputs | 8 |
| Propagation Delay | 50pF | Number of Channels | 8 |
| Number of Elements | 1 | Current Rating (Max) | Catalog |
| Frequency - Output 1 | 25 | Schmitt Trigger Input | No |
| Voltage - Supply (Min) | 5.5 V | Propagation Delay (Max) | 53 |
| Current - Quiescent (Iq) | 8 uA | Delay Time - Propagation | 28 ns at 4.5 V |
| Current - Quiescent (Max) | 0.08 | Current - Output High, Low | - 6 mA |
| Number of Bits per Element | 8 | Current - Output Source/Sink | -6/6 |
| Max Propagation Delay @ V, Max CL | 28@4.5V ns | Propagation Delay tpLH / tpHL (Max) | 29 |
| Common Mode Transient Immunity (Min) | Military | ||
Mechanical
| Width | 7.52mm | Height | 2.35mm |
| Length | 12.8mm | Weight | 0.017662 oz |
| Packaging | Tube | Lead Style | Gull-wing |
| Termination | :SMD | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :20 |
| Package / Case | 20SOIC | Package Cooled | SOIC |
| Material Finish | :MSL 1 - Unlimited | Length - Overall | 13(Max) |
| Package Quantity | SOIC | Size / Dimension | 12.8 x 7.52 x 2.35mm |
| Number of Positions | 20 | Shell Size - Insert | 2.35(Max) |
| Supplier Device Package | 20-SOIC | ||
Product Info
| Spg | 25 | Type | digital |
| Series | CD74HCT541 | DELETED | Compliant |
| Process | CMOS | Function | Buffer/Line Driver |
| Polarity | Non-Inverting | Software | SCHS189C |
| Base Unit | :74 | Technology | CMOS |
| Number of Units | 1 | RF Family/Standard | HCT |
| Utilized IC / Part | 3-state, line driver, octal buffer | Printed Circuit Board | 20 |
Environmental
| Temperature - Test | -55 to 125 | Operating Temperature | + 125 C |
Documents & Media
Similar Parts
CD74HCT541E
texas instruments
Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin PDIP Tube IC BUFF/DVR TRI-ST 8BIT 20DIP CD74HCT541E, 8-Bit Buffer, Line Driver, HCT, 3-State Non-Inverting 5V 20-Pin PDIP Buffers & Line Drivers Hi Spd CMOS Oct Non Invr Bfr & Line Drvr IC, 74HCT CMOS, 74HCT541, DIP20, 5V High Speed CMOS Logic Octal Non-Inverting Buffers and Line Drivers with 3-State Outputs HCT, 8-Bit 三态 非反相 缓冲器，线路驱动器, 20针 PDIP封装
SN74HCT541PW
