CC2540F128RHAT

Manufacturer	Texas Instruments Incorporated
Description	Bluetooth Class II 1Mbps 40-Pin VQFN EP T/R RF System on a Chip - SoC 2.4GHz Bluetooth Lo Energy SOC Sol IC SOC 2.4GHZ BLUETOOTH 40VQFN CC2540F128RHAT, System-On-Chip Microcontroller CMOS for Bluetooth, 2 to 3.6V 40-Pin VQFN IC, SOC, RF, 128K, 2.4GHZ, 40VQFN SimpleLink Bluetooth Smart Wireless MCU with USB Texas Instruments 片上系统 SOC, 微控制器, CMOS技术, 用于蓝牙, 2 → 3.6 V, 40针 VQFN封装 RF Microcontrollers - MCU RF Bluetooth SMART SOC with USB BLE
Category	Connector SolutionsTerminal BlocksScrew Terminal Blocks

对参数有疑问？问 AI 助手

Business

Other Names	296-27921-2	Product Category	RF System on a Chip - SoC
Standard Package	Tape & Reel	Factory Pack Quantity	250
Standard Package Name	QFN

Compliance

RoHS	RoHS Compliant	SVHC	:No SVHC (16-Dec-2013)
EU RoHS	Compliant	Tariff No	85423190
Part Status	ACTIVE	Rad Hardened	No

Electrical

Core Type	8051	Data Rate	1 Mbps
Frequency	2.4 GHz	Modulation	:GFSK
Memory Size	8 KB	Power Level	Class II
Sensitivity	3	Output Power	8 dBm
Data Interface	PCB, Surface Mount	Power - Output	8dBm
Voltage Rating	2 V	Data Rate (Max)	1 Mbps
Frequency - Max	:2.48GHz	Frequency - Min	:2.402GHz
Frequency Range	:2.402GHz to 2.48GHz	Current - Supply	0.0004 A
Voltage - Supply	2 to 3.6 V	Number of Channels	3
Current - Receiving	22.1mA	Program Memory Size	128 KB
Current Rating (Max)	0.0000004(Typ) A	Frequency - Operating	2402
Current - Transmitting	31.6mA	Voltage - Supply (Min)	3.6 V
Current - Supply (Main IC)	31.6 mA	Distance - Control To Sensor (Max)	Personal (~10m)
Common Mode Transient Immunity (Min)	Industrial

Mechanical

Width	6 mm	Height	0.9mm
Length	6 mm	Weight	0.00022
Packaging	Reel	Lead Style	No Lead
Mounting Type	Surface Mount	Mounting Style	SMD/SMT
Number of Pins	:40	Package / Case	40VQFN EP
Package Cooled	VQFN	Material Finish	:MSL 3 - 168 hours
Length - Overall	6.15(Max)	Package Quantity	VQFN EP
Size / Dimension	6 x 6 x 0.9mm	Antenna Connector	PCB, Surface Mount
Number of Positions	40	Shell Size - Insert	0.95(Max)
Number of Cores/Bus Width	8 bit

Product Info

Type	Bluetooth	Series	CC2540
DELETED	Compliant	Features	Yes
Protocol	Yes	Software	SWRS084F
Topology	Star or Point to Point	Technology	CMOS
Application	Bluetooth Smart (Bluetooth low energy)	On-Chip RAM	Yes
Applications	General Purpose	Pattern Number	Y
Number of Nodes	<10	Number of Timers	21
Operating System	Android Linux RTOS No OS	Functional Diagram	fbd_swrs084f.gif
Network Technology	Use direct link to phone/tablet/pc Use custom gateway or not required	Utilized IC / Part	View
Application Specifics	Bluetooth	Printed Circuit Board	40
Battery Type, Function	Coin Cell AAA Battery AA Battery Rechargable (Li-ION)	Modulation or Protocol	Bluetooth Low Energy, v4.0

Environmental

Temperature - Test	-40 to 85	Operating Temperature	- 40 C to + 85 C
Operating Temperature - Junction	85C

Documents & Media

PDF Document

Cu Wire QFN Packages 25/Apr/2013

PDF Document

CC2540F128,256 Datasheet

PDF Document

cc2540.pdf
