BQ24074RGTT
| Manufacturer | |
| Description | Battery Charger Li-Ion 1500mA 4.2V 16-Pin VQFN EP T/R IC LI-ION BATTER CHARGER 16-QFN Battery Management Li-Ion Batt Chrgr & Pwr-Path Mgmt IC USB-Friendly Li-Ion Battery Charger and Power-Path Management IC, 10.5V OVP Texas Instruments 锂离子 电池充电器, 4500mA最大输出, 16针 QFN封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Charge Management | Other Names | 296-23798-2 |
| Product Category | Battery Management | Standard Package | Cut Tape |
| Factory Pack Quantity | 250 | Standard Package Name | QFN |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Part Status | ACTIVE | Rad Hardened | No |
Electrical
| Charge Time | Yes | Voltage Rating | 4.2 V |
| Current - Output | 1500(Max) mA | Voltage - Supply | 4.35 V ~ 26 V |
| Regulator Topology | Linear | Current Rating (Max) | 4500mA |
| Voltage - Output (Max) | 4.4 V | Voltage - Supply (Min) | 4.35 V |
| Current - Supply (Main IC) | 1.5 | ||
Mechanical
| Width | 3.15mm | Height | 0.95mm |
| Length | 3.15mm | Weight | 0.000808 oz |
| Packaging | Tape and Reel | Lead Style | No Lead |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | 16 | Package / Case | 16VQFN EP |
| Package Cooled | VQFN EP | Length - Overall | 3.15(Max) |
| Package Quantity | VQFN EP | Size / Dimension | 3.15 x 3.15 x 0.95mm |
| Number of Positions | 16 | Shell Size - Insert | 0.95(Max) |
| Supplier Device Package | 16-QFN (3x3) | ||
Product Info
| Type | Battery Charger | Series | BQ24074 |
| DELETED | Compliant | Features | Over Voltage Protection Power Path |
| Function | Charge Management | Software | SLUS810K |
| Manufacturer | Texas Instruments | Product Type | Charge Management |
| Development Kit | BQ24074EVM | Battery Chemistry | Li-Ion |
| Control Interface | Standalone | Functional Diagram | alt_slus810k.gif |
| Utilized IC / Part | View | Printed Circuit Board | 16 |
Environmental
| Temperature - Test | -40 to 85 | Temperature Display | Yes |
| Operating Temperature | -40 to 125 °C | ||
