2BDC20SLP20SLP110VAC
| Manufacturer | |
| Description | Time Delay Relay Tempatron 2BDC20SLP20SLP110VAC, 0.5 to 20s 8-Pin Connector DPDT 240 V ac, 30 V dc Tempatron 单 计时继电器, 0.5 → 20S, DP 常开/常闭, 2触点, DPDT, 110 V 交流 |
| Category |
对参数有疑问？问 AI 助手
Electrical
| Delay Time | 200 (Reset) ms | Range deg/s | 0.5 → 20 s |
| Voltage - Max | 240 V ac, 30 V dc | Operating Mode | Delay Cycle |
| Delay Time - OFF | 秒 | Voltage - Supply | 110 V ac |
| Power Supply Type | External | Current Rating (Max) | 10 A |
| Switch Function/Rating | DPDT | ||
Mechanical
| Depth | 108mm | Width | 48mm |
| Length | 48mm | Mounting Type | Plug In |
| Terminal Type | 8-Pin Connector | Connector Type | 8 引脚连接器 |
| Contact Material | Silver Cadmium Oxide | Number of Contacts | 2 |
| Contact Layout, Typical | DP-NO/NC | ||
Product Info
| Switch Type | DPDT | Number of Timers | 单 |
| Number of Macrocells | Single | ||
Environmental
| Operating Range | 0.5 → 20 s | Operating Temperature | +60°C |
