Compliance
| RoHS | Exempt | SVHC | :Bis (2-ethylhexyl)phthalate (DEHP) (20-Jun-2013) |
| Tariff No | 90303100 | Safety Category | CAT II 300 V |
Electrical
| Memory | 1Mpts | Channels | 4 + 16 |
| Frequency | 100s/div | Display Type | LCD - Touch Screen |
| Voltage Rating | 300 V | Input Impedance | 1 MΩ |
| Rise Time (Typ) | 5ns | Voltage - Supply | Mains |
| Input Capacitance | 11.5 pF | Resolution (Bits) | 1 (Digital) bit, 8 (Analogue) bit |
| Number of Channels | 4 | Sampling Frequency | 1 GS/s |
| Sensitivity (mV/g) | 5V/div | Sampling Rate (Per Second) | 1 G samples/s |
Mechanical
| Depth | :134mm | Width | 134mm |
| Height | 180mm | Length | 377mm |
| Weight | 3.6kg | Bandwidth | 70MHz |
| Height (Max) | :180mm | Length - Overall | 1M points/ch |
| Size / Dimension | 377 x 134 x 180mm | ||
Product Info
| USB | Yes | Type | MixedSignal |
| Series | MSO2000B | Hook Type | :Bench |
| Calibration | UKAS | Manufacturer | MSO2000BSeries |
| Model Number | MSO2004B | Configuration | Bench/Portable |
| Equipment Type | Mixed Signal Oscilloscopes | Channels per Circuit | :4 Analogue, 16 Digital |
| Diagonal Screen Size | 180 mm, 7 in | ||
Environmental
| Operating Temperature | +50°C | ||
