BMB2A0120BN3
| Manufacturer | |
| Description | EMIフィルタ ビーズ、チョーク、アレイ BMB-B 0805 120R EMI Filter Beads, Chips & Arrays BMB-B 0805 120R FERRITE BEAD, 300MA, 0805 FERRITE BEAD, 0.4OHM, 300MA, 0805 TE Connectivity BMBA 系列 铁氧体磁珠, 0805封装, 适用于高频 BMB-B 0805 120R |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Ferrite Chip Beads | メーカ | TE Connectivity |
| Part # Aliases | 1624117-6 | ||
Compliance
| RoHS | RoHS 認証 | Tariff No | 85045020 |
Electrical
| Impedance | 120 Ohms | Tolerance | 25 % |
| Resistance | :0.4ohm | Test Frequency | 100 MHz |
| Current Rating - DC | :300mA | Current Rating (Max) | 300 mA |
| Impedance @ Frequency | :120ohm | DC Resistance (DCR) (Max) | :0.4ohm |
| Resistance - Initial (Ri) (Min) | 400 mOhms | ||
Mechanical
| Depth | :2mm | Width | 1.25 mm |
| Length | :0.9mm | Weight | 0.000004 |
| Packaging | :Cut Tape | Core Material | :Ferrite |
| Reel Capacity | :500 | Package / Case | 2 mm |
| Mounting Feature | :SMD | Size / Dimension | 1.25 mm W x 2 mm L x 0.9 mm H |
| Tape Width - Max | :8mm | Termination Style | SMD/SMT |
Product Info
| Series | :BMB-B | Equipment Part Numbers | 1624117-6 |
Environmental
| Mechanical Life | Mouser 初 | Operating Temperature | - 55 C to + 125 C |
