1394738-2
| Manufacturer | |
| Description | Solar Connectors / Photovoltaic Connectors DC CONV RCPT 2.5MMsq PLASTIC NUT MINUS SOLARLOK Connector System CONN RECEPT 14AWG MINUS KEYED DC CONVERTER, SOLARLOK, MINUS, 2.5MM DCCONVERTERRECEPTACLE,W/ORINGANDMETALNUT,14AWG,2.5MM2,KEYING=MINUS,TU ANSCHL.WECHSELRICHT |
| Category |
Business
| Product | Cable Couplers | Lead Time | 59 Days |
| Other Names | 13947382 | Subcategory | Connector Photovoltaic |
| Product Category | Solar Connectors / Photovoltaic Connectors | Standard Package | 100 |
| Factory Pack Quantity | 100 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| Leadfree Defin | Not relevant for lead free process | RoHSELV Compliance | RoHS compliant, ELV compliant |
Mechanical
| Weight | 0.05 | Wire Gauge | 14 |
| Housing Color | Black | Connector Type | Junction Box Receptacle |
| Contact Finish | Silver Plate | Mounting Style | Wire |
| Contact Material | Copper Zinc | Housing Material | PPO |
| Package Quantity | 100 | Termination Style | Quick Connect |
| Color - Connectors | :Black | Number of Contacts | :1 |
| Contact Termination | :Crimp | Wire Gauge or Range - mm2 | 2.5² [14] |
| 1st Connector Mounting Type | :Panel | ||
Product Info
| Type | Converter Receptacle, Male Pin | Gender | Male |
| Series | :SOLARLOK | Features | 14 AWG |
| Function | Solarlok connector | Key Type | Minus |
| Coded, Keyed | Yes | Product Type | Connector |
Documents & Media
Similar Parts
1394462-4
te connectivity / amp
Conn Power F 1 POS Solder ST Thru-Hole 1 Terminal PHOTOVOLTAIC PRODUCTS CONN FEMALE MINUS COUPLER 12AWG Female Cable Mount Solar Connector Coupler,Cable CSA 4mm2,Rated At 25A,1000V dc Solar Connectors / Photovoltaic Connectors CABLE COUPLER FEMALE MINUS KEYED 4.0 Conn Female Cable Coupler 12AWG Conn Female Cable Coupler 12AWG Product Highlights:ConnectorConnector Type = Cable CouplerFemaleKeyedKeying = MinusSearch Keywords:IEC 61215, 61646, Protection Class II, Photovoltaic Interconnection System, high voltage, high current, photovoltaic, solar, ground clip, solar panels, solar panel, ground PV panels, photovoltaics, solar cable, solar cable coupler, Photovoltaic Interconnection System, Decentralized junction box, residential combiner box, 5-string Combiner Box SOCKET, SOLARLOK, 4MM, NEG CONNECTOR,PHOTOVOLTAIC,SOLARLOK,CABLECOUPLER,1POS.,FEMALE,MINUS,12AWG Connector: DC mains; Features: "-" marking; female; 4mm2 Solarlok 12 AWG Minus Keying Black Female Cable Coupler Connector TE Connectivity 电缆安装 管接头 太阳能面板接头 , 截面积4mm²电缆, 额定25A, 1000 V 直流 PHOTOVOLT STEVERB1P
C31008-000
TE Connectivity
CONN FEMALE CABLE COUPLER 14AWG
97 49 68 1
Knipex
Positioning Aid POSITIONER FOR 97 49 68 Positioning aid Positioning aid for 97 49 68, 97 49 68 1, Knipex
97 49 68
