V23092A1005A201
| Manufacturer | |
| Description | General Purpose Relays RELAY PWR SPDT RELAY GENERAL PURPOSE SPDT 6A 5V Relay,slim,PCB,SPDT,6A,5Vdc coil Electromechanical Relay SPDT 10A 5VDC 147Ohm Through Hole Electromechanical Relay SPDT 10A 5VDC 147Ohm Through Hole Product Highlights:SNR SeriesContact Arrangement = 1 Form C, SPDT, 1 C/OContact Current Rating = 6 Amps.Monostable Coil Magnetic SystemWithout Coil Suppression Diode Relay,slim,PCB,SPDT,6A,5Vdccoil General Purpose Relay Coil Voltage: 5 VDC Contact Configuration: 1C SPDT Current: 6 Amps Mounting: PC Board Operating Function: Single Side Stable TE Connectivity 单刀双掷 PCB（印刷电路板）安装 非闭锁继电器, 5V dc V23092A1005A201=SNR |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 1393236-1 | Part # Aliases | 1393236-1 |
| Product Category | General Purpose Relays | Standard Package | 1,000 |
Compliance
| RoHS | RoHS Compliant | Leadfree Defin | Wave solder capable to 240C, Wave solder capable to 260C, Wave solder capable to 265C |
| Approved Countries | UL Recognized, CSA Component Acceptance, VDE Component Mark | RoHS/ELV Compliance | Converted to comply with RoHS directive |
| FCC Part 68 Isolation | No | ||
Electrical
| Current | 6 Amps | Coil Type | Monostable |
| Core Type | Monostable | Coil Power | 170 mW |
| Coil Current | 34mA | Release Time | 5ms |
| Power - Input | 210 mW | Isolation Type | 4000V rms |
| Visible Output | Without | Voltage - Core | 3500 – 4000 |
| Voltage Rating | 250 | Coil Resistance | 147 Ohms |
| Current - Surge | 6 | Voltage - Supply | 5VDC |
| Switching Voltage | 400VAC - Max | Power - Peak Pulse | 1.5 kVA |
| Vgs(th) (Max) @ Id | 0.25 VDC | Connector Impedance | 1 Form C (CO) |
| Current - Switching | 6 A | Current - Trip (It) | 10 |
| Diode Configuration | Without | Current Rating (Max) | 10 |
| Frequency - Output 1 | 单稳态、直流 | Power - Output Surge | 1500 VA |
| Current Rating (Amps) | 5 – 10, 16 | Insulation Resistance | 8 mm [ .315 in ] |
| Voltage - Switching AC | 400V 交流 | Current Rating - Series | Sensitive |
| Power - Average Forward | 170 mW | Vce(on) (Max) @ Vge, Ic | 3.5 VDC |
| Contact Rating (Current) | 6A | Current - Output Source/Sink | 100mA @ 12V |
| Current - Peak Pulse (8/20us) | 6 A | Current - Discharge (Max) (8/20uS) | 6 |
| Voltage - Anode - Cathode (Vak)(Max) | 400 | ||
Mechanical
| Depth | 5mm | Width | 5 mm |
| Height | 15 mm | Length | 28 mm |
| Weight | 6 g [ .2116 oz ] | Packaging | Bulk |
| Insulation | 继电器基极 PTI250 的跟踪指数 | Termination | Through Hole |
| Contact Form | 1 Form C (SPDT-BM) | Height (Max) | 14 – 15 |
| Actuator Type | DC | Mounting Type | Through Hole |
| Terminal Type | Through Hole | Mounting Style | SMD/SMT |
| Coil Insulation | n/a | Contact Material | Silver Tin Oxide |
| Size / Dimension | 28 x 5 x 15mm | Insulation Height | 5.5 – 8 |
| Outline L x W x H | 5.00 x 28.00 x 15.00 [.197 x 1.103 x .591] | Termination Style | PC Pin |
| Number of Contacts | 1 | Insulation Diameter | 6 mm [ .236 in ] |
| Insulation Material | 4kV rms | Width / Cross Section | 0 – 6 |
| Contact Layout, Typical | SPDT | Supplier Device Package | Sealed |
| 1st Connector Mounting Type | 印刷电路板 | ||
Product Info
| Note | n/a | Type | Relays |
| Series | SNR | Features | Sealed - Fully |
| Function | Single Side Stable | Polarity | No |
| Relay Type | General Purpose | Card Standard | General Purpose Relay |
| Wiring Diagram | 1 Form C | ||
Environmental
| Operate Time | 12ms | Ingress Protection | RTIII |
| Operating Temperature | -40°C ~ 85°C | Maximum Temperature Limit | +85°C |
| Initial Dielectric Strength | 1000 | ||
