W67-X2Q52-10
| Manufacturer | |
| Description | Circuit Breakers 10A 1 POLE TOGGLE CIR BRKR MAG-HYDR 10A 65VDC Circuit Breaker Magnetic Hydraulic 1Pole 10A 65VDC Circuit Breaker Magnetic Hydraulic 1Pole 10A 65VDC Product Highlights:Series/Mounting Option = W6 (6-32 Mtg. Threads)Actuator Style = ToggleNumber of Poles = 1Current Rating = 10 Amps.Toggle Color = White CIRCUIT BREAKER, HYD-MAG, 1P, 65V, 10A W67-X2Q52-10=M6/M7/M9/W6/W7 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Hydraulic Magnetic Circuit Breakers | Lead Time | 84 Days |
| Subcategory | Circuit Breaker | Part # Aliases | 8-1393252-1 |
| Product Category | Circuit Breakers | Standard Package | 24 |
| Factory Pack Quantity | 24 | ||
Compliance
| RoHS | RoHS Compliant By Exemption | Tariff No | 85361010 |
Electrical
| Voltage Rating | 65 V | Number of Poles | 1 Pole |
| Dielectric Strength | 1.5 kV | Current Rating (Max) | 10 A |
| Voltage - Input (Min) | :2kA | Voltage - Supply (Min) | :65VDC |
Mechanical
| Color | White | Width | 19.05 mm |
| Height | 50.8 mm | Length | 51.89 mm |
| Weight | 2.497397 oz | Breaker Type | Magnetic (Hydraulic Delay) |
| Actuator Type | Toggle | Mounting Type | Panel Mount |
| Mounting Style | Panel | Termination Style | Quick Connect |
Product Info
| Type | Circuit Breaker | Series | W6 |
| Function | Series Trip | Illumination | No |
| Product Type | Supplementary Protector / Motor Controller | Industry Aliases | 8-1393252-1, W67-X2Q52-10 |
Environmental
| Time to Trip | 2.2 s to 20 s | Operating Temperature | - 40 C to + 85 C |
