W57-XB7A4A10-20
| Manufacturer | |
| Description | Circuit Breakers 20A PUSH TO RESET CIR BRKR THRM 20A 250VAC CircuitBreaker,Therm,Press-to-Reset Circuit Breaker Thermal 1Pole 20A 250VAC Circuit Breaker Thermal 1Pole 20A 250VAC Product Highlights:Circuit BreakerW57 Series1 PolesActuator Style = Push to ResetCurrent Rating = 20 A CircuitBreaker;Therm;Press-to-Reset;Cur-Rtg20A;Panel;1Pole;Vol-Rtg250VAC TE Connectivity W57 系列 1 极 20A 热磁断路器 W57-XB7A4A10-20=CKTBKR,THERM,P |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Thermal Circuit Breakers | Part # Aliases | 1-1423675-0 |
| Product Category | Circuit Breakers | Standard Package | 200 |
| Factory Pack Quantity | 200 | ||
Compliance
| RoHS | RoHS Compliant By Exemption | Standards | ULRecognized |
| Part Status | 1-1423675-0 | ||
Electrical
| Input | .48 x .433 | Lamp Type | 不发光 |
| Trip Status | 4 – 40 | Voltage Rating | 250 V |
| Number of Poles | 1 Pole | Voltage - Supply | 250 |
| Dielectric Strength | 1.5 kVAC | Current Rating (Max) | 20 A |
| Light Emitting Surface (LES) | 否 | ||
Mechanical
| Color | White | Width | 14.6 mm |
| Height | 29.2 mm | Length | 22.6 mm |
| Weight | 0.504418 oz | Termination | QuickConnect |
| Breaker Type | Thermal | Actuator Type | Pushbutton |
| Mounting Type | Panel Mount | Connector Type | 不带 |
| Mounting Style | Panel | Material - Core | Metal |
| Mounting Feature | 已装配至衬套 | Primary Material | CircuitBreaker |
| Size / Dimension | 0.889Lx0.575Wx1.15Hin. | Termination Style | Quick Connect |
| Color - Connectors | 白色带红色额定值标记（垂直） | Color - Actuator/Cap | WhitewithRedRateMarking(Vertical) |
| Bushing, Grommet Type | 10.8 x 12.6 mm 长，金属 | Mounting Hole Diameter | D-Shaped,0.48Dia.x0.433Hin. |
Product Info
| Type | Push to Reset only Circuit Breaker | Series | W57 |
| Features | UL1077Recognized | Function | Series Trip |
| Illumination | No | Manufacturer | W57Series |
| Product Type | Supplementary Protector | ||
Environmental
| Time to Trip | 5 s to 40 s | Operating Temperature | 0 C to + 60 C |
