1-1721958-1
| Manufacturer | |
| Description | ORWH-SH-105HM3F,000 General Purpose / Industrial Relays ORWH-SH-105HM3F 000 RELAY GEN PURPOSE SPST 10A 5V |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Pack | 1 | Standard Package | 25 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Coil Type | Non Latching | Coil Power | 360 mW |
| Coil Current | 71.4mA | Release Time | 5ms |
| Coil Resistance | 70 Ohms | Voltage - Supply | 5VDC |
| Switching Voltage | 277VAC, 28VDC - Max | Vgs(th) (Max) @ Id | 0.5 VDC |
| Vce(on) (Max) @ Vge, Ic | 3.5 VDC | Contact Rating (Current) | 10A |
Mechanical
| Packaging | Tube | Contact Form | SPST-NO (1 Form A) |
| Mounting Type | Through Hole | Contact Material | Silver Nickel (AgNi) |
| Termination Style | PC Pin | ||
Product Info
| Features | Insulation - Class F, Sealed - Fully | Relay Type | General Purpose |
Environmental
| Operate Time | 10ms | Operating Temperature | -30°C ~ 70°C |
