D2D0305N
| Manufacturer | |
| Description | SWITCH ROTARY 3P-5POS OPEN FRAME SWITCH ROTARY 3P-5POS OPEN 28V Rotary Switches 02-05POS/3P/1SECTION SWITCH, ROTARY, 3P5T, 550mA, 115V Switch,Rotary;3Poles;2-5Positions;1Section;Non-shorting;0.55A;28VDC;SolderT. |
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 35 Days | Other Names | 451-1059 |
| Subcategory | Switch Rotary | Product Category | Rotary Switches |
| Standard Package | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 00000000 |
Electrical
| Voltage - Core | :115V | Voltage Rating | 115 V |
| Number of Poles | :3 | Dielectric Strength | 750VAC |
| Current Rating (Max) | 550 mA | Current - Max/Contact | :250mA |
| Contact Rating @ Voltage | 0.55A @ 28VDC | Voltage - Supply (Vcc/Vdd) | :28V |
Mechanical
| Weight | 0.036 | Orientation | Vertical |
| Termination | SolderLugs | Contact Type | Non Shorting |
| Actuator Type | Round (6.35mm dia) | Mounting Type | Panel Mount |
| Angle of Throw | 30° | Contact Finish | Silver |
| Mounting Style | Panel | Rotation Angle | :30° |
| Contact Material | Brass | Termination Style | Solder Lug |
| Number of Positions | 2 ~ 5 | Material - Insulation | DiallylPhthalate |
| Mounting Hole Diameter | 3/8In. | Number of Poles per Deck | 3 |
Product Info
| Type | Rotary | Index Stops | Adjustable |
| Manufacturer | D2Series | Number of Decks | 1 |
| Circuit per Deck | 3P5T | ||
Environmental
| Rated Life | 25000Cycle | ||
