969973-4
| Manufacturer | |
| Description | Conn Socket Strip RCP 8 POS 2.54mm Solder ST SMD T/R Headers & Wire Housings RECPT ASSY 2X04P HV-100 .100 inch AMPMODU Receptacles CONN RCPT DUAL ENTRY 8POS .100" .100 inch AMPMODU Receptacles Product Highlights:ConnectorWith ContactsHousing Gender = Connector - ReceptacleContact Gender = ReceptacleHV-100Search Keywords:AMPMODU, board to board, NIC, Network Interface Cards, PC Cards, MIL-C-55032, MIL-C-24519, pcb connectors, wire to board, signal, RECEPTACLE, SMT, 2X4WAY 2x4P HV100 REC. CON, SMD, GOLD, BLISTER |
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | AMPMODU | Other Names | A107058CT |
| Standard Pack | 700 | Product Category | Headers & Wire Housings |
| Standard Package | Tape & Reel | Factory Pack Quantity | 700 |
Compliance
| RoHS | RoHS Compliant | Tariff No | 85369010 |
| Leadfree Defin | Reflow solder capable to 245°C, Reflow solder capable to 260°C | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Approval Agency Marking | No | Material Flammability Rating | UL 94V-0 |
Electrical
| Range deg/s | :TE - AMPMODU HV-100 Series | Voltage Rating | 250 V |
| Voltage - Working | :250V | Contact Resistance | 12 mohm |
| Connector Impedance | Bottom or Top | Current Rating (Max) | 3 A |
| Voltage - Supply (Min) | 250VAC | ||
Mechanical
| Color | Black | Pitch | 2.54 mm |
| Height | 6.2 mm | Sealed | No |
| Weight | 0.001 | Packaging | Reel |
| Row Spacing | 0.100" (2.54mm) | Termination | Solder |
| Holding Type | Without | Pitch - Post | 2.54 [.100] |
| Mounting Type | Vertical | Cable End Type | With |
| Connector Type | 6.20 [0.244] | Contact Finish | Gold |
| Mounting Style | SMD/SMT | Number of Rows | 2 |
| Profile (W x H) | Standard | Contact Material | Phosphor Bronze |
| Housing Material | Liquid Crystal Polymer (LCP) | Termination Style | Solder |
| 1st Contact Gender | Socket (Female) | Height Above Board | 0.244" (6.20mm) |
| Number of Contacts | 8 | Termination Finish | Tin (100) over Nickel (50) |
| Contact Termination | :Surface Mount Vertical | Number of Positions | 8 |
| Contact Finish Thickness | 31.5µin (0.80µm) | 1st Connector Mounting Type | :PC Board |
Product Info
| Type | Socket Strip | Gender | RCP |
| Series | AMPMODU HV-100 | DELETED | Compliant |
| Stackable | Yes | Manufacturer | AMP |
| Product Type | Receptacles / Sockets - PCB | Other Specifications | Without |
| Number of Positions Loaded | All | ||
Environmental
| Operating Temperature | -65C to 125C | ||
