796640-2
| Manufacturer | |
| Description | Conn Terminal Block F 2 POS 5mm Screw RA Cable Mount 15A/Contact Pluggable Terminal Blocks 5.0MM RA PLUG 2P Terminal Block Connectors TERM BLOCK PLUG 2POS STR 5MM Conn Terminal Block F 2 POS 5mm Screw RA Cable Mount 15A/Contact Product Highlights:ConnectorConnector Type = PlugNot ShroudedHousing Color = GreenSide StackableSearch Keywords:cage clamp, modular, one-piece, pcb, stackable, end-to-end TERMINAL BLOCK PLUGGABLE, 2POS, 30-12AWG Conn;TermBlk;Plug;Screw;2;5mm;RightAngle;30-12AWG;Green;15A;300V;M3 2 POS 5.0 MM R/A PLUG,TRM BLK |
| Category |
Business
| Product | Pluggable Terminal Blocks | Product Category | Pluggable Terminal Blocks |
| Standard Package | Bulk | Factory Pack Quantity | 300 |
Compliance
| RoHS | RoHS Compliant | Tariff No | 85366910 |
| Rad Hardened | No | Leadfree Defin | Not relevant for lead free process |
| Approval Agency | UL94V-0 | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Current | 15A | Voltage | 300V |
| Voltage Rating | 300 VAC | Number of Poles | 2Poles |
| Voltage - Supply | 300 | Current Rating (Max) | 15 A |
| Voltage - Supply (Min) | 300VAC | ||
Mechanical
| Color | Green | Depth | 18.4 mm |
| Pitch | 5 mm | Height | 15.5 mm |
| Weight | 0.004 | Packaging | Bulk |
| Shrouding | No | Lead Style | Side |
| Screw Size | M3 | Wire Gauge | 12-30 AWG |
| Termination | Screw | Housing Color | Green |
| Mounting Type | Cable Mount | Connector Type | Plug |
| Contact Finish | Tin | Flange Feature | Without |
| Mounting Style | Through Hole | Number of Rows | 1 |
| Screw Material | Brass | Plug Wire Entry | 180° |
| Contact Material | Phosphor Bronze | Housing Material | Polyamide (PA) |
| Length - Overall | 5.00 [0.197] | Primary Material | PCB |
| Pin Hole Diameter | 0.197(5)In.(mm) | Pitch - Connector | Side |
| Termination Style | Screw | Number of Contacts | 2 |
| Number of Positions | 2 | Terminal Block Type | Plug, Female Sockets |
| Wire Entry Location | Front | Screw Material - Plating | Nickel |
| Wire Gauge or Range - AWG | 30-12 | Wire Gauge or Range - mm2 | 12 |
| 1st Connector Mounting Type | :Cable | ||
Product Info
| Type | Terminal Block | Level | SingleLevel |
| Gender | F | Series | :- |
| Features | Retention Latches (Non-Wire Side) | Manufacturer | Buchanan |
| Product Type | Connector | Side Stackable | Yes |
| Number of Levels | 1 | Interconnect System | Without |
| Positions Per Level | 2 | ||
Environmental
| Operating Temperature | -40C to 105C | ||
Documents & Media
