RoHS	Lead free / RoHS Compliant	Leadfree Defin	Wave solder capable to 240Â°C
RoHSELV Compliance	RoHS compliant, ELV compliant	Material Flammability Rating	UL 94V-0

Size	Half	Color	Gray
Pitch	2.54 mm	Coating	Without
Packaging	Bulk	Shielding	否
Termination	Solder	Contact Size	0.60 [.024] Sq.
Contact Type	Solder Post	Mounting Type	Through Hole
Connector Type	Plug, Male Pins	Contact Finish	Gold or Gold-Palladium
Contact Timing	否	Mounting Style	带有
Number of Rows	3	Height (Inches)	12.62
Insert Material	磷青铜	Contact Material	Copper Alloy
Housing Material	Polyester GF 30%	Mounting Feature	With
Panel Mount Type	通孔 - 焊接	Size / Dimension	半
Make Before Break	No	Pitch - Connector	2.54
Termination Style	插针	Number of Contacts	48
Contact Tail Length	3	Number of Positions	48
Contact Length - Post	信号（数据）	Material - Insulation	Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Mounting Hole Diameter	带有	Termination Post Length	3.00 [0.118]

Type	DIN 41612	Grade	II
Style	1/2 C	Gender	Plug
Features	Board Lock	Guide Method	不带
Product Type	Type C Connectors	Connection Type	Printed Circuit Board
Number of Columns	32	Tool Type Feature	No
Number of Positions Loaded	All	Number of Positions (Convert To)	每两个间距

Temperature	No	Level, Class	2
Operating Temperature	-55°C ~ 125°C	Thermal Resistance of Package	1.6 mm [ .063 in ]

7-1393644-4
