640445-3
| Manufacturer | |
| Description | Conn Wire to Board HDR 3 POS 3.96mm Solder ST Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER VERT 3POS .156 TIN TE Connectivity MTA-156 Series 3.96mm Pitch 3 Way 1 Row Straight PCB Header, Solder Termination, 7A Headers & Wire Housings FRCTN LK HDR STR 3P Square post tin Conn Wire to Board HDR 3 POS 3.96mm Solder ST Thru-Hole Product Highlights:MTA-156 ConnectorsNumber of Positions = 3Mating Type = HeaderWire-to-Board Application3.96 mm Contact Centerline SpacingSearch Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP HEADER, VERTICAL, 0.156", 3WAY Connector,MTA-156;Male;3;CopperAlloy;7;600;0.156in.;Polyester;White Connector: wire-board; Series: MTA-156; 3.96mm; male; socket; PIN:3 Pin header straight 3P, 640445-3, TE Connectivity TE Connectivity MTA-156 系列 3.96mm节距 3路 (1排) 直 PCB 针座, 焊接端接, 7A , 通孔 03P MTA156 HDR ASSY FL/STR SN |
| Category |
Business
| Product Category | Headers & Wire Housings | Standard Package | Bulk |
| Factory Pack Quantity | 2000 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | UL94V-0HousingFlammabilityRating,RoHSCompliant,ELVCompliant |
| Tariff No | 85423990 | Approval Agency | CSA,UL |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Range deg/s | :TE - MTA-156 Series | Voltage Rating | 600 V ac |
| Switch Function | Friction Lock | Voltage - Working | :250V |
| Contact Resistance | 3 mohm | Current Rating (Max) | 7A |
| Voltage - Supply (Min) | 600VAC | ||
Mechanical
| Color | Natural | Depth | 7.62 mm |
| Pitch | 3.96 mm | Height | 13.33 mm |
| Weight | 0.098 | Packaging | Bulk |
| Wire Gauge | 26-18 | Orientation | straight |
| Termination | Solder | Contact Type | Male Pin |
| Lead Spacing | :3.96mm | Length - Pin | 0.125" |
| Pitch - Post | 3.96mm | Housing Color | White |
| Mounting Type | Through Hole | Angle of Throw | Straight |
| Connector Type | Header, Unshrouded | Contact Finish | Tin Over Nickel |
| Fastening Type | Friction Lock | Mounting Style | Through Hole |
| Number of Rows | 1 | Contact Material | Copper Alloy |
| Housing Material | Polyester | Length - Overall | 11.89 mm |
| Package Quantity | 1 | Primary Material | InterconnectSystem |
| Connector - Cable | socket | Pin Hole Diameter | 0.156" |
| Termination Style | Through Hole | 1st Contact Gender | Pin (Male) |
| Number of Contacts | 3 | Contact Termination | :Through Hole Vertical |
| Insulation Diameter | 0.095"(SingleWire),0.07"(MassTerminationWires) | Number of Positions | 3 |
| Center Contact Plating | 0.156in. | Length - Post (Mating) | 0.125in. |
| Mounting Hole Diameter | 0.07" | Contact Length - Mating | 0.400" (10.16mm) |
| Termination Post Length | 3.18 mm | Contact Material - Plating | tinned |
| 1st Connector Mounting Feature | 1x3 | ||
Product Info
| Spg | 1 | Type | Wire to Board |
| Gender | HDR | Series | MTA-156 |
| Features | IDC,Pinstrip | Manufacturer | MTA-156Series |
| Product Type | Headers | Adapter Series | MTA-156 |
| Number of Units | 1 | Application Specifics | Wire-to-Board |
| Number of Positions Loaded | All | ||
