640440-5
| Manufacturer | |
| Description | Conn IDC Connector F 5 POS 2.54mm IDT RA Cable Mount Loose Piece MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN RECEPT 5POS 22AWG MTA100 Headers & Wire Housings CLOSED W/O TABS 5P red tin 22 AWG Conn IDC Connector F 5 POS 2.54mm IDT RA Cable Mount Loose Piece Product Highlights:MTA-100 ConnectorsNumber of Positions = 5Mating Type = ReceptacleConnector Type = Closed EndWire-to-Board Application, Wire-to-Wire ApplicationSearch Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP MTA-100CONNECTORTIN,05PMTA100CONNASSY22AWGRED 05P MTA100 CONN ASSY 22AWG RED |
| Category |
Business
| Other Names | A19011 | Product Category | Headers & Wire Housings |
| Standard Package | Bulk | Factory Pack Quantity | 1 |
Compliance
| RoHS | Contains lead / RoHS non-compliant | UL Rating | 获得认可 |
| Leadfree Defin | Not relevant for lead free process | UL File Number | E28476 |
| CSA File Number | LR7189 | Standard Number | CSA, UL |
| CSA Certification | Certified | RoHSELV Compliance | Not ELV/RoHS compliant |
| Material Flammability Rating | UL 94V-2 | ||
Electrical
| Voltage Rating | 250 VAC | Switch Function | Ramp Lock |
| Voltage - Supply | 250 | Contact Resistance | 6 mohm |
| Voltage - Rated AC | 250 | Connector Impedance | IDC |
| Current Rating (Max) | 5 A | Voltage - Supply (Min) | 250VAC |
Mechanical
| Color | Red | Depth | 6.99 mm |
| Pitch | 2.54 mm | Height | 13.21 mm |
| Length | 12.7 mm [ .5 in ] | Packaging | Bulk |
| Shrouding | No | Wire Type | Discrete or Ribbon Cable |
| Body Color | 红色 | Cable Exit | 90° |
| Cable Type | Discrete or Ribbon Cable | Wire Gauge | 22 AWG |
| Termination | IDT | Contact Form | Female Socket |
| Contact Type | Female Socket | 2nd Connector | With |
| Housing Color | Red | Mounting Type | Free Hanging (In-Line) |
| Connector Type | Closed End | Contact Finish | Tin-Lead Over Nickel |
| Contact Timing | Without | Fastening Type | Locking Ramp |
| Mounting Style | Wire | Number of Rows | 1 |
| Shell Material | 标准 | Connector Usage | Receptacle |
| Insert Material | 铜合金 | Contact Material | Copper Alloy |
| Housing Material | Nylon | Length - Overall | 12.7 mm |
| Mounting Feature | Without | Package Quantity | Loose Piece |
| Panel Mount Type | Without | Primary Material | InterconnectSystem |
| Cable Termination | IDC | Termination Style | IDC |
| 1st Contact Gender | Socket (Female) | Mating Orientation | Without |
| Number of Contacts | 5 | Termination Finish | 带有 |
| Contact Termination | Locking Lance | Insulation Diameter | 1.52 mm [ .06 in ] |
| Number of Positions | 5 | Compatible Shell Size | MTA .100 头和 MTA .100 IDC 柱形连接器 |
| Mounting Hole Diameter | 不带 | Contact Finish - Mating | 锡铅 |
| Contact Layout, Typical | 2.54 [0.100] | Surface Mount Land Size | Without |
| Contact Finish Thickness | 80µin (2.03µm) | Small Diameter Recovered | No |
| Wire Gauge or Range - mm2 | 0.3-0.4² [22] | Static Discharge Shielding | 带有 |
Product Info
| Note | 肋之间的条纹可能会减少 | Type | IDC Connector |
| Gender | F | Series | MTA-100 |
| Features | Closed End | Sealable | 否 |
| Main Purpose | Closed End | Manufacturer | AMP |
| Product Type | MTA-100 Connectors | Connection Type | Wire |
| Output Configuration | Free Hanging (In-Line) | Number of Positions Omitted | None |
Environmental
| Operating Temperature | -55C to 105C | ||
Documents & Media
