5747841-6
| Manufacturer | |
| Description | Conn D-Subminiature PIN 15 POS 2.74mm Solder RA Thru-Hole 15 Terminal 1 Port D-Sub Standard Connectors PLUG FRNT MTL SHL 15 Standard Board Mount Connectors CONN D-SUB PLUG R/A 15POS GOLD AMPLIMITE HD-20 d-sub PCB plug, 15 pin Conn D-Subminiature PIN 15 POS 2.74mm Solder RA Thru-Hole 15 Terminal 1 Port Product Highlights:Number of Positions = 15PlugPCB Mount Angle = Right AngleProduct Series = HD 20With Mating Connector LockSearch Keywords:Subminiature D, AMPLIMITE, MIL-C-24308, DIN 41652, Mark II, Mark III, DIN 41494, box to box, military/aerospace, 13C3, 3C3, HD-22,
ACTION PIN, d-sub, d sub, dsub D SUB CONNECTOR, STANDARD, 15POS, PLUG Conn;D-Sub;PCBPlug;15Pos;RTAng;HD-20Series;20AWG;FrontMetalShell TE Connectivity Amplimite HD-20 系列 2.74mm 节距 15 路 直角 通孔安装 PCB D-sub 连接器 插头 15 MSFL PLUG RA 318 (SL,FM,BL) |
| Category |
Business
| Product Category | D-Sub Standard Connectors | Standard Package | Trays |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85366910 | Rad Hardened | No |
| Leadfree Defin | Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Grounding | Without | Range deg/s | :TE CONNECTIVITY - Amplimite HD-20 Series |
| Voltage Rating | 125V | Current Rating (Max) | 6A |
| Voltage - Input (Min) | 250VDC|250VAC | Voltage - Supply (Min) | 250VDC/250VAC |
Mechanical
| Color | Black | Depth | 18.62mm |
| Pitch | 2.74 mm | Width | 12.55mm |
| Height | 12.55 mm | Length | 39.14mm |
| Sealed | No | Weight | 0.005 |
| Plating | Tin over Nickel | Packaging | Tray |
| Shell Size | 2 | Termination | Solder |
| Contact Type | Signal | 2nd Connector | With |
| Contact Shape | Round | Mounting Type | Through Hole |
| Shell Plating | Tin | Connector Type | Plug, Male Pins |
| Contact Finish | Gold | Flange Feature | Mating Side; Female Screwlock (4-40) |
| Grounding Type | With | Material - Tip | Tin over Copper Flash |
| Mounting Style | Through Hole | Number of Rows | 2 |
| Shell Material | Steel | Board Thickness | 0.062 [1.57] |
| Connector Style | D-Sub | Locking Feature | Female Screwlocks, Fixed |
| Material - Body | :Metal | Profile (W x H) | Standard |
| Contact Material | Brass | Housing Material | Nylon|Polyester |
| Length - Overall | 39.14 mm | Panel Mount Type | Without |
| Size / Dimension | 0.66 [.026] | Grounding Indents | With |
| Outline L x W x H | 8.08 [.318] | Termination Style | Solder |
| 1st Contact Gender | PIN | Color - Connectors | None |
| Number of Contacts | 15 | Contact Termination | :Through Hole Vertical |
| Number of Positions | 15 | Shell Size - Insert | Front Metal Shell |
| Mounting Hole Diameter | 3.18 [.125] | Shell Material, Finish | Steel, Tin Plated |
| Termination Post Length | 3.18 [0.125] | Contact Finish Thickness | Flash |
| Screw Material - Plating | Clear Chromate | Shell Size, Connector Layout | 2 (DA, A) |
Product Info
| Note | Plugs are preloaded with size 20 DF posted pin contacts | Type | D-Subminiature |
| Gender | PIN | Series | HD-20 |
| Features | Board Lock, Ground Strap, Grounding Indents | Manufacturer | AMP |
| Number of Ports | 1 | ||
Environmental
| Operating Temperature | -55°C ~ 105°C | ||
