535542-8

Manufacturer	TE Connectivity Ltd.
Description	Conn Socket Strip SKT 16 POS 2.54mm Solder ST Thru-Hole Gang of Tubes .100 inch AMPMODU Receptacles CONN RECEPT 16POS .100 VERT DUAL Headers & Wire Housings 16 MODIV VRT DR CE 100/130 Conn Socket Strip SKT 16 POS 2.54mm Solder ST Thru-Hole Gang of Tubes Search Keywords:AMPMODU, board to board, NIC, Network Interface Cards, PC Cards, MIL-C-55032, MIL-C-24519, pcb connectors, wire to board, signal, 16 MODIV VRT DR CE 100/130
Category	Connector SolutionsBoard to Board ConnectorsBoard-to-Board Connectors

对参数有疑问？问 AI 助手

Business

Tradename	AMPMODU	Product Category	Headers & Wire Housings
Standard Package	Rail / Tube	Factory Pack Quantity	28

Compliance

RoHS	Not applicable / RoHS non-compliant	MIL-C-55032	否
Standard Number	CSA LR7189, UL E28476	Material Flammability Rating	UL 94V-0

Electrical

Contact Resistance	12	Resistance - Input	5000
Voltage - Clamping	750	Voltage - Rated AC	333
Current Rating (Max)	2 A

Mechanical

Color	Black	Pitch	2.54 mm
Height	5.03 mm [ .198 in ]	Packaging	Tube
Body Color	黑色	Lead Style	正方形
Row Spacing	0.100" (2.54mm)	Termination	Solder
Contact Type	Female Socket	Mounting Type	Through Hole
Connector Type	Receptacle	Contact Finish	Gold Over Nickel
Mounting Style	低	Number of Rows	2
Pressure (PSI)	标准	Terminal Style	短点
Connector Usage	底部或顶部, 闭合入口	Insert Material	磷青铜
Contact Material	Phosphor Bronze	Housing Material	Polycyclohexylenedimethylene Terephthalate (PCT)
Package Quantity	28	Panel Mount Type	通孔 - 焊接
Pitch - Connector	.15	Termination Style	Through Hole
Number of Contacts	16	Contact Tail Length	3.18
Number of Positions	16	Bushing, Grommet Type	不带
Compatible Shell Size	与接头配合	Termination Post Length	3.3 mm [ .13 in ]
Contact Finish Thickness	30µin (0.76µm)

Product Info

Note	TE 建议使用接合金或带双层电镀母端配件的双层电镀公端。, 为了获得最小接合柱长度，在最大触点尺寸上增加 .51 [.020]（不包含斜面上的柱引线）。	Type	Socket Strip
Gender	SKT	Series	AMPMODU MOD IV
Sealable	否	Stackable	是
Product Type	Receptacles / Sockets - PCB	Assembly Configuration	板支座
Number of Positions Loaded	All

Environmental

Temperature - Test	否	Operating Temperature	- 65 C to + 105 C
Thermal Resistance of Package	1.57 mm [ .062 in ]
