535512-5

Manufacturer	TE Connectivity Ltd.
Description	Conn Socket Strip SKT 36 POS 2.54mm Solder RA Thru-Hole Gang of Tubes .100 inch AMPMODU Receptacles CONN RECEPT 36POS .100 RT/A DUAL Headers & Wire Housings 100X100 REC 2X18P R/A T/H C/E Conn Socket Strip SKT 36 POS 2.54mm Solder RA Thru-Hole Gang of Tubes Product Highlights:ReceptacleMod IINumber of Positions = 36Number of Rows = DualStandard ProfileSearch Keywords:AMPMODU, board to board, NIC, Network Interface Cards, PC Cards, MIL-C-55032, MIL-C-24519, pcb connectors, wire to board, signal, 36 MODII HORZ DR CE
Category	Connector SolutionsBoard to Board ConnectorsBoard-to-Board Connectors

对参数有疑问？问 AI 助手

Business

RoHS	Contains lead / RoHS non-compliant	MIL-C-55032	否
Standard Number	CSA LR7189, UL E28476	Material Flammability Rating	UL 94V-0

Color	Black	Pitch	2.54 mm
Height	6.05 mm [ .238 in ]	Packaging	Tube
Row Spacing	0.100" (2.54mm)	Termination	Solder
Contact Type	Female Socket	Mounting Type	Through Hole, Right Angle
Connector Type	Receptacle	Contact Finish	Gold Over Nickel
Mounting Style	标准	Number of Rows	2
Pressure (PSI)	标准, 高	Terminal Style	短点
Connector Usage	侧, 闭合入口	Insert Material	磷青铜
Contact Material	Phosphor Bronze	Housing Material	Polycyclohexylenedimethylene Terephthalate (PCT)
Package Quantity	12	Panel Mount Type	通孔 - 焊接
Pitch - Connector	.31	Termination Style	Through Hole
Number of Contacts	36	Contact Tail Length	2.92
Number of Positions	36	Bushing, Grommet Type	不带
Compatible Shell Size	与接头配合	Termination Post Length	3 mm [ .1 in ]
Contact Finish Thickness	30µin (0.76µm)

Note	TE 建议使用接合金或带双层电镀母端配件的双层电镀公端。, 停止使用最小为 6.50 [.256] 的正极插针，以防止行与行之间发生短路。	Type	Socket Strip
Gender	SKT	Series	AMPMODU MOD II
Sealable	否	Stackable	是
Product Type	Receptacles / Sockets - PCB	Assembly Configuration	板支座
Number of Positions Loaded	All
