5222006-1
| Manufacturer | |
| Description | Conn BNC RCP 50Ohm Press Fit ST Thru-Hole Gold BNC RF Connectors CONN BNC JACK STR 50 OHM PCB RF Connectors / Coaxial Connectors PRESS-FIT TERM. JACK Conn BNC RCP 50Ohm Press Fit ST Thru-Hole Gold Product Highlights:ConnectorConnector Type = BNCJackTerminate To Printed Circuit BoardPCB Mount Angle = VerticalSearch Keywords:solderless, RF, coax, BNC, UG/U, miniature, sub-miniature, bayonet, MIL-C-39012 RF/COAXIAL, BNC JACK STR 50 OHM PRESS FIT BNC50OHMBOARDMNT,RECEPTACLE,PRESSFIT,COMLBNC TE Connectivity BNC 直 50Ω 通孔 BNC 连接器, 插口, 焊接 端接, 镀镍本体 RECEPTACLE,PRESS FIT,COML BNC |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | PCB Connectors | Product Category | RF Connectors / Coaxial Connectors |
| Standard Package | Rail / Tube | Factory Pack Quantity | 50 |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 00000000 |
| Rad Hardened | No | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant, ELV compliant | Approval Agency Marking | No |
Electrical
| Impedance | 50 Ohm | Isolated Power | No |
| Voltage Rating | 500 V | Frequency - Max | 4GHz |
| Connector Impedance | Without | Insulation Resistance | 5000 MOhms |
Mechanical
| Size | Standard | Height | 20.57 mm |
| Sealed | No | Weight | 0.005 |
| Diameter | 11.94 mm | Packaging | Bulk |
| Cable Type | :(Not Available) | Body Finish | Nickel |
| Orientation | Straight | Termination | Press Fit |
| Body Material | Zinc | Mounting Type | Through Hole |
| Angle of Throw | Straight | Connector Type | BNC |
| Contact Finish | Gold | Fastening Type | Bayonet Lock |
| Housing Finish | Nickel | Mounting Style | Through Hole |
| Plating - Body | Nickel | Connector Style | BNC |
| Height (Inches) | 20.57 [0.810] | Contact Material | Beryllium Copper |
| Panel Mount Type | Without | Primary Material | BNC |
| Termination Style | Solder | Shield Termination | Press-Fit |
| Contact Termination | Solder | Dielectric Material | TEFLON |
| Insulation Material | Polytetrafluoroethyl | Center Contact Plating | Gold |
| Center Contact Material | Beryllium Copper | Supplier Device Package | Straight |
| Surface Mount Land Size | No | ||
Product Info
| Type | BNC | Grade | Commercial |
| Gender | RCP | Series | :- |
| Hardware | No | Polarity | No |
| Manufacturer | AMP | Product Type | Connector |
| Connection Type | PCB | Number of Ports | 1 |
| RF Family/Standard | 5222006 | ||
Environmental
| Operating Temperature | - 55 C to + 85 C | ||
