3-917241-6
| Manufacturer | |
| Description | Conn Housing M 12 POS 5.08mm Crimp ST Cable Mount Bag Headers & Wire Housings 12 POS HOUSING TAB DUAL PANEL MOUNT Dynamic Series Connectors CONN HOUSING TAB 12POS DUAL PANL Conn Housing M 12 POS 5.08mm Crimp ST Cable Mount Bag Product Highlights:Terminate To WireHousingTabNumber of Positions = 12Mount = Panel MountSearch Keywords:wire-to-board, wire-to-wire, process computers, inverters, power, power, Dynamic Series Connectors, Dynamic Series, HMI, Human Machine Interfaces, Multiple Enclosure Connector; DYNAPAC, Dynamic, DYNAMIC D-3500 TAB HSG 12P P/M |
| Category |
Business
| Other Names | A29676 | Product Category | Headers & Wire Housings |
| Standard Package | Bulk | Factory Pack Quantity | 100 |
Compliance
| RoHS | RoHS Compliant | UL Rating | 获得认可 |
| Leadfree Defin | Not relevant for lead free process | UL File Number | E28476 |
| CSA File Number | LR7189 | Standard Number | CSA, UL |
| CSA Certification | Certified | Approved Countries | 是 |
| RoHSELV Compliance | RoHS compliant, ELV compliant | Approval Agency Marking | 否 |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage - Supply | 600 | Voltage - Rated AC | 600 |
| Voltage - Supply (Min) | 600VAC | ||
Mechanical
| Color | Black | Depth | 33.6 mm |
| Pitch | 5.08 mm | Width | 21.52 mm [ .847 in ] |
| Height | 21.52 mm | Length | 52 mm [ 2.047 in ] |
| Packaging | Bulk | Body Color | 黑色 |
| Wire Gauge | 16 AWG | Row Spacing | 0.200" (5.08mm) |
| Contact Type | Male Pin | Housing Color | Black |
| Mounting Type | Straight | Connector Type | Plug |
| Mounting Style | Wire | Number of Rows | 2 |
| Insertion Force | 9.8 牛顿 | Housing Material | Thermoplastic Polyester |
| Length - Overall | 52 mm | Package Quantity | Bag |
| Panel Mount Type | 带有 | Termination Style | Crimp |
| Number of Contacts | 12 | Contact Termination | Crimp |
| Number of Positions | 12 | Compatible Shell Size | 母端护套 |
| Contact Layout, Typical | 网络 | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | M | Series | D3500D |
| Sealable | 否 | Coded, Keyed | No |
| Preinstalled | 否 | Product Type | Plugs - Housings |
| Connection Type | Wire | Selectively Loaded | No |
| Other Specifications | Without | ||
Environmental
| Temperature - Test | 标准部件 - 非辉光导线 | Operating Temperature | -55C to 105C |
Documents & Media
Similar Parts
