3-87631-1

Manufacturer	TE Connectivity Ltd.
Description	Conn Housing RCP 36 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN RCPT HSG 36POS DL CRIMP Headers & Wire Housings 36 MODIV HSG COMP DR .100 POL Conn Housing RCP 36 POS 2.54mm Crimp ST Cable Mount Product Highlights:Receptacle HousingWire Termination Type = CrimpNumber of Positions = 36Housing Type = ReceptacleNumber of Rows = DualSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE 36 MODIV HSG COMP DR .100 POL
Category	Integrated CircuitsGeneral Purpose ICsMemory Controllers

对参数有疑问？问 AI 助手

Business

Tradename	AMPMODU	Product Category	Headers & Wire Housings
Standard Package	Bulk

Compliance

RoHS	Lead free / RoHS Compliant	Standard Number	CSA LR7189, UL E28476
Material Flammability Rating	UL 94V-0

Electrical

Voltage Rating	250 V	Switch Function	Detent Latching
Voltage - Supply	250 VAC	Contact Resistance	12 mΩ
Resistance - Input	5000	Connector Impedance	压接
Current Rating (Max)	3 A	Voltage - Supply (Min)	250VAC
Voltage - Protection Rating (VPR)	750 V

Mechanical

Color	Black	Depth	15.24 mm
Pitch	2.54 mm	Height	6.1 mm [ .24 in ]
Length	45.72 mm [ 1.8 in ]	Lock Type	带有
Packaging	Bulk	Body Color	黑色
Wire Gauge	20-30 AWG	Row Spacing	0.100" (2.54mm)
Contact Type	Female Socket	Housing Color	Black
Mounting Type	Straight	Connector Type	Receptacle
Fastening Type	Locking Ramp	Number of Rows	2
Insert Material	铍铜	Contact Material	Phosphor Bronze
Housing Material	Nylon	Length - Overall	45.72 mm
Package Quantity	1	Termination Style	Crimp
1st Contact Gender	Socket (Female)	Number of Contacts	36
Contact Termination	Crimp	Number of Positions	36
Compatible Shell Size	公端	Mounting Hole Diameter	带有
Static Discharge Shielding	不带

Product Info

Note	Contacts Not Provided	Type	Housing
Gender	RCP	Series	AMPMODU MOD IV
Product Type	Receptacles / Sockets - Housings	Number of Taps/Steps	2
Other Specifications	否	Application Specifics	Board to Board

Environmental

Temperature - Test

标准部件 - 非辉光导线

Operating Temperature

- 65 C to + 105 C
