3-794679-4
| Manufacturer | |
| Description | Conn Power HDR 4 POS 3mm Solder RA Thru-Hole 4 Terminal 1 Port 3mm Centerline, 250V, 5 A max. CONN HEADER 4POS DL R/A 30GOLD Pin & Socket Connectors 04P MICRO MNL ASSY R/A THRU LF 3mm Centerline, 250V, 5 A max. Product Highlights:Header AssemblyNumber of Positions = 4Number of Rows = DualRight Angle Mount AngleMount Style = Through-HoleSearch Keywords:wire to board, wire to wire, high density, Power Pin & Socket, Soft Shell, Lighting Interconnection, wire to panel, power, pcb connectors, discrete wire, crimp,
low profile, Micro MATE-N-LOK connector, MATE-N-LOK connector, Low Profile Soft Shell connector, Lighting, LED Lighting, Lighting Applications, Soft Shell connector, Low profile Micro MATE-N-LOK connector 04P MICRO MNL ASSY,R/A,THRU,LF |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Pack | 377 | Product Category | Pin & Socket Connectors |
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | UL Rating | 获得认可 |
| Part Status | E28476 | Leadfree Defin | Reflow solder capable to 245°C, Reflow solder capable to 260°C |
| CSA File Number | LR7189 | Standard Number | CSA, UL |
| CSA Classification | 已认证 | RoHSELV Compliance | RoHS compliant, ELV compliant |
| UL Flammability Rating | UL 94V-0 | Approval Agency Marking | 是 |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage - Supply | 250 | Current Rating (Max) | 5 |
Mechanical
| Color | Black | Pitch | 3 mm |
| Sealed | Not Sealed | Plating | Tin |
| Packaging | Tray | Body Color | 黑色 |
| Row Spacing | 0.118" (3.00mm) | Termination | Solder |
| Contact Type | Male Pin | Polarization | Without |
| Housing Color | Black | Mounting Type | Through Hole |
| Connector Type | Header, Shrouded | Contact Finish | Matte Tin |
| Fastening Type | Locking Ramp | Mounting Style | Through-Hole |
| Number of Pins | 4 | Number of Rows | Dual |
| Contact Material | Brass | Housing Material | High Temperature Nylon |
| Length - Overall | 3.00 [0.118] | Mounting Feature | 板锁 |
| Package Quantity | 377 | Panel Mount Type | 通孔 - 焊接 |
| Termination Style | 插针 | 1st Contact Gender | Pin (Male) |
| Insulation Diameter | 1.52 | Number of Positions | 4 |
| Shell Size - Insert | 插头 | Compatible Shell Size | 双排插座外壳 |
| Mounting Hole Diameter | 带有 | Contact Finish - Mating | 哑光 |
| Termination Post Length | 3.18 mm [ .125 in ] | Contact Finish Thickness | 30µin (0.76µm) |
| Static Discharge Shielding | 不带 | Backshell Material, Plating | 磷青铜 |
Product Info
| Type | Power | Gender | HDR |
| Series | Micro Mate-N-Lok | Features | Board Lock |
| Manufacturer | AMP | Product Type | Header Assembly |
| Application Specifics | Power | Number of Positions Loaded | All |
Environmental
| Temperature - Test | 标准件 - 非灼热丝 | Operating Temperature | -40 – 105 °C [ -40 – 221 °F ] |
| Thermal Resistance of Package | 1.57 mm [ .062 in ] | ||
