3-644501-7
| Manufacturer | |
| Description | Conn IDC Connector F 7 POS 3.96mm IDT RA Cable Mount MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN RCPT 7POS 22AWG MTA-156 Headers & Wire Housings 07P MTA156 CONN ASSY 22AWG LF 07P MTA156 CONN ASSY 22AWG LF |
| Category |
Business
| Product Category | Headers & Wire Housings | Standard Package | Bulk |
Compliance
| RoHS | Lead free / RoHS Compliant | UL Rating | 获得认可 |
| UL File Number | E28476 | CSA File Number | LR7189 |
| Standard Number | CSA, UL | CSA Classification | 已认证 |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage Rating | 600 VAC | Voltage - Supply | 600 |
| Connector Impedance | IDC | Current Rating (Max) | 7 A |
Mechanical
| Color | Black | Pitch | 3.96 mm |
| Height | 9.02 mm [ .355 in ] | Length | 27.74 mm [ 1.092 in ] |
| Packaging | Bulk | Wire Type | Discrete or Ribbon Cable |
| Body Color | 黑色 | Cable Type | 分离式导线, 绞线 |
| Wire Gauge | 22 AWG | Termination | IDT |
| Contact Type | Female Socket | Mounting Type | Free Hanging (In-Line) |
| Connector Type | Receptacle | Contact Finish | Tin |
| Contact Timing | Without | Fastening Type | Locking Ramp |
| Mounting Style | Wire | Number of Rows | 1 |
| Plating - Body | Nickel | Shell Material | 标准 |
| Insert Material | 铜合金 | Contact Material | Copper Alloy |
| Housing Material | Nylon | Package Quantity | 250 |
| Panel Mount Type | 不带 | Cable Termination | IDC |
| Termination Style | IDC | 1st Contact Gender | Socket (Female) |
| Number of Contacts | 7 | Termination Finish | 带有 |
| Insulation Diameter | 2.41 mm [ .095 in ] | Number of Positions | 7 |
| Compatible Shell Size | MTA .156 头 | Mounting Hole Diameter | 不带 |
| Contact Finish - Mating | 锡 | Contact Layout, Typical | 同轴 |
| Contact Finish Thickness | 80µin (2.03µm) | Static Discharge Shielding | 带有 |
| Jacket (Insulation) Thickness | .762 µm, 30 µin | ||
Product Info
| Type | IDC Connector | Gender | F |
| Series | MTA-156 | Features | Closed End |
| Sealable | 否 | Product Type | Connector Assemblies |
Environmental
| Operating Temperature | -55 – 105 °C [ -67 – 221 °F ] | ||
