281839-8
| Manufacturer | |
| Description | Conn Housing RCP 16 POS 2.54mm Crimp ST Loose Piece .100 AMPMODU Headers, Housings & Contacts CONN HOUSING RCPT DUAL 16POS 16way double row HE14 crimp socket shell Headers & Wire Housings RECPT 2X08 POS Conn Housing RCP 16 POS 2.54mm Crimp ST Loose Piece Product Highlights:Receptacle HousingWire Termination Type = Crimp, Insulation Displacement Crimp (IDC)Number of Positions = 8Housing Type = ReceptacleNumber of Rows = DualSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE CRIMP HOUSING, 2 ROW, 16WAY Connector: wire-board; HE14; plug; female; for cable; PIN:16 Cable socket housing Pitch2.54 mm Poles 2 x 8 HE-14, 281839-8, TE Connectivity TE Connectivity AMPMODU HE13/HE14 系列 2 行 2.54mm 节距 8 路 直 母 电缆安装 PCB 连接器外壳 HOUSING HE13 HE14 COSI 2X8 P |
| Category |
Business
| Product Category | Headers & Wire Housings | Standard Package | Bulk |
| Factory Pack Quantity | 500 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| Leadfree Defin | Not relevant for lead free process | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Range deg/s | :TE - AMPMODU HE13 / HE14 Series | Current Rating (Max) | :3A |
| Connector - Voltage Input | w/o terminals | ||
Mechanical
| Color | Blue | Depth | 15mm |
| Pitch | 2.54 mm | Width | 7.62mm |
| Length | 20.32mm | Weight | 0.0176 |
| Packaging | Bulk | Row Spacing | 0.100" (2.54mm) |
| Termination | :Crimp | Contact Type | Female Socket |
| Pitch - Post | 2.54 [.100] | 2nd Connector | Without |
| Housing Color | Blue | Mounting Type | Straight |
| Connector Type | Crimp, Insulation Displacement Crimp (IDC) | Contact Finish | :- |
| Mounting Style | for cable | Number of Rows | 2 |
| Package / Case | Receptacle | Contact Material | :- |
| Housing Material | PBT - GF | Package Quantity | Loose Piece |
| Connector - Cable | plug | Termination Style | Crimp |
| 1st Contact Gender | Socket (Female) | Mating Orientation | Without |
| Number of Contacts | 16 | Contact Termination | Crimp |
| Number of Positions | 8 | 1st Connector Mounting Type | :PCB |
| 1st Connector Mounting Feature | 2x8 | ||
Product Info
| Spg | 20 | Note | Contacts Not Provided |
| Type | Housing | Gender | RCP |
| Series | HE13 / HE14 | Preloaded | No |
| CAD Drawing | 3D CAD Model | Coded, Keyed | No |
| Product Type | Housing | Adapter Series | HE14 |
| Number of Units | 1 | For Use With/Related Products | Modular Headers and Plug to IEC 60603-8 Series |
