Business
| Product | Micro Ribbon Connectors | Lead Time | 28 Days |
| Subcategory | Connector Interface | Product Category | Connectors |
| Standard Package | Trays | Factory Pack Quantity | 1 |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| Leadfree Defin | Not relevant for lead free process | RoHSELV Compliance | RoHS compliant, ELV compliant |
Electrical
| Voltage - Supply (Min) | 250VAC | ||
Mechanical
| Color | Black | Depth | 15.37 mm |
| Pitch | 2.16 mm | Height | 17.53 mm |
| Weight | 0.009 | Packaging | Tray |
| Thickness | Thick | Cable Type | 7 Strand, Solid |
| Wire Gauge | 24-26AWG(Solid),24AWG(Stranded) | Copper Type | B |
| Shield Type | No | Termination | IDC |
| 2nd Connector | With | Housing Color | Blue |
| Mounting Type | Cable Mount | Angle of Throw | Straight |
| Connector Type | Plug | Contact Finish | Gold (30) over Nickel (50), Gold Flash over Palladium Nickel over Nickel |
| Flange Feature | Insert, Threaded (4-40) | Mounting Style | PCB |
| Number of Rows | 2 | Connector Style | PS |
| Locking Feature | Screwlocks | Profile (W x H) | Standard |
| Contact Material | Copper Alloy | Housing Material | Thermoplastic |
| Length - Overall | 83.32 mm | Package Quantity | Tray |
| Panel Mount Type | Without | Primary Material | Industrial |
| Pin Hole Diameter | 0.85" | Termination Style | Wire |
| Number of Contacts | 50 | Contact Termination | :IDC / IDT |
| Insulation Diameter | 1.14 [.045] Max. | Number of Positions | 50 |
| Contact Finish Thickness | 30µin (0.76µm) | Wire Gauge or Range - mm2 | 0.20² [24] |
| 1st Connector Mounting Type | :Cable | ||
Product Info
| Type | IEEE 488 | Gender | PL |
| Series | :Champ | Features | IDC connectors |
| Manufacturer | CHAMP-LOK | Product Type | Connector |
| Number of Ports | 1 Port | ||
Environmental
| Operating Temperature | -40C to 75C | Operating Temperature - Junction | -40C |
Documents & Media
Online Document
Online Document
Online Document
