213845-3

Business

Tradename	Multimate	Product Category	Standard Circular Contacts
Standard Package	Bulk	Factory Pack Quantity	100

RoHS

Lead free / RoHS Compliant

Tariff No

85369010

Current Rating (Max)

50 A

Pitch	Not Required mm	Weight	0.002
Plating	Silver	Material	Copper
Packaging	Bulk	Wire Gauge	12-14 AWG
Termination	Crimp	Contact Size	:8
Contact Type	Power	Mounting Type	Straight
Pin or Socket	Pin	Connector Type	Connector Power
Contact Finish	Silver Over Nickel	Mounting Style	Cable
Contact Material	Copper	Housing Material	Not Required
1st Contact Gender	Pin (Male)	Color - Connectors	:Silver
Number of Contacts	1 POS	Contact Termination	Crimp
Plating - Thickness	200µin (5.08µm)	Wire Gauge or Range - AWG	:12AWG
Wire Gauge or Range - mm2	:3mm²	Diameter - Outside, Non-Expanded	:1.63mm

Type	Power	Gender	PIN
Series	Multimate Powerband	CAD Drawing	3D CAD Model
Number of Ports	1 Port	For Use With/Related Products	:0.125 POWERBAND Contact Series Connectors
