212526-1
| Manufacturer | |
| Description | Conn D-Subminiature RCP 1Power/21Signal POS Solder ST Cable Mount 22Terminal 1Port D-Sub Mixed Contact Connectors RECEPT ASSY,21C1,AMP 25 Subminiature D Pin/Socket Connectors for MIL-C-24308 and MIL-C-39029 CONN D-SUB RECEPT 109 MIX 21C1 Conn Housing RCP 1Coaxial/21Signal POS Crimp ST Conn Housing RCP 1Coaxial/21Signal POS Crimp ST Product Highlights:ConnectorProduct Series = 109Density = StandardTerminate To Coaxial Cable, Terminate To Printed Circuit Board, Terminate To WireInsert Arrangement = 21C1Search Keywords:AMPLIMITE, rack and panel, MIL-M24519, DIN 41652, input/output, box to box, military/aerospace, d-sub, d sub, dsub RECEPT ASSY,21C1,AMPLIMITE |
| Category |
Business
| Product Category | D-Sub Mixed Contact Connectors | Standard Package | Bulk |
Compliance
| RoHS | No | Qualification | No |
| Leadfree Defin | Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c | RoHSELV Compliance | Not ELV/RoHS compliant |
| Other Specifications | 否 | Approval Agency Marking | No |
Electrical
| Connector Impedance | Yes | Connector - Voltage Input | 否 |
Mechanical
| Color | Blue | Outline | 3 |
| Material | Stainless Steel | Packaging | Bulk |
| Shell Size | 3 | Termination | Solder |
| Contact Size | 20 | Contact Type | Coax or Power and Signal |
| Non-Magnetic | No | Shell Finish | 镉 |
| Mounting Type | Cable Mount | Shell Plating | Cadmium |
| Terminal Size | 20, 8 | Connector Type | Receptacle for Female Contacts |
| Flange Feature | Housing/Shell (Unthreaded) | Mounting Style | Wire |
| Number of Rows | 2 | Shell Material | Steel |
| Connector Style | D-Sub, Combo | Insertion Angle | 21C1 |
| Housing Material | 钢 | Connector - Cable | 是 |
| Termination Style | 插座 | Number of Contacts | 1Power/21Signal POS |
| Dielectric Material | Polyester, Glass Filled | Number of Positions | 21 (20 + 1 Coax or Power) |
| Bushing, Grommet Type | No | Mounting Hole Diameter | 3.05 [.120] |
| Shell Material, Finish | Steel, Cadmium Plated | Contact Material - Post | 不锈钢 |
| Shell Size, Connector Layout | 3 (DB, B) - 21W1 | ||
Product Info
| Note | Cable clamp/strain relief hardware cannot be used with these arrangements. | Type | D-Subminiature |
| Gender | RCP | Series | 109 |
| Density | Standard | Arrangement | 21C1 |
| Socket Type | Without | Manufacturer | AMP |
| Product Type | Connector | Connection Type | Coaxial Cable, Printed Circuit Board, Wire |
