Business

Lead Time63 DaysTradenameCPC Series 1
SubcategoryConnector CircularProduct CategoryStandard Circular Connector
Standard PackageBulkFactory Pack Quantity10

Compliance

RoHSLead free / RoHS CompliantTariff No85369010
ComplianceNoLeadfree DefinNot relevant for lead free process
RoHSELV ComplianceRoHS compliant / ELV compliantMaterial Flammability RatingUL 94V-0

Electrical

ResistanceNoneVoltage Rating:250V
Voltage - Working:250VNumber of Channels37.0
Current Rating (Max):13A

Mechanical

ColorBlackSealedNo
Weight0.2PackagingBulk
Shell Size28OrientationKeyed
Shell StylePlugTerminationCrimp
Thread Size1-7/16 - 18 UNEF-2AContact Size16
Contact TypeSocketHousing ColorBlack
Mounting TypeCable MountShell PlatingNickel
Angle of ThrowStraightConnector TypeHousing
Fastening TypeThreaded CouplingHousing FinishNickel
Mounting StyleFree HangingPackage / Case:Zinc Alloy
Shell MaterialZinc alloyConnector StylePlug
Insertion Angle:28-37Material - Body:Thermoplastic
Housing MaterialThermoplastic - GFPrimary MaterialCircularPlasticConnector
1st Contact GenderFemaleColor - Connectors:Nickel
Mating OrientationKeyedNumber of Contacts37
Insulation Diameter2.54Number of Positions0.0
Shell Size - InsertMetalShell Material, FinishZinc, Nickel Plated
1st Connector Mounting Type:Cable2nd Connector Mounting FeatureStandard

Product Info

NoteContacts Not ProvidedTypeMetal Shell CPC
GenderPLSeriesSeries 1
Arrangement28-37CAD Drawing3D CAD Model
ManufacturerAMPProduct TypeHousings
Other SpecificationsWithoutApplication SpecificsCommercial

Environmental

Ingress ProtectionWithoutOperating Temperature+125°C

Documents & Media

Online Document

Sourcing & traceability

Datasheet
208470-1

Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
