206794-4
| Manufacturer | |
| Description | Contact PIN Crimp ST Cable Mount Loose Piece D-Sub Contacts PIN CONTACT, SZ 20 AMPLIMITE - Aerospace & Military CONN PIN 26-28AWG CRIMP GOLD 109 Series Pin Contact size 20 28-26AWG 206794-4 Contact PIN Crimp ST Cable Mount Loose Piece Product Highlights:ContactProduct Series = 109Terminate To WirePinContact Size = 20Search Keywords:AMPLIMITE, rack and panel, MIL-M24519, DIN 41652, input/output, box to box, military/aerospace, d-sub, d sub, dsub PINCONTACT,SZ20 TE Connectivity AMPLIMITE 109 Series系列 尺寸20触点 公 压接 D-sub 连接器触点, 镀金镀铜 触点, 28 → 26 AWG PIN CONTACT, SZ 20 |
| Category |
Business
| Product Category | D-Sub Contacts | Standard Package | Bulk |
Compliance
| RoHS | RoHS Compliant | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant / ELV compliant | Approval Agency Marking | No |
Electrical
| Connector Impedance | 压接 | Current Rating (Max) | 否 |
| Connector - Voltage Input | Crimp | Current - Output High, Low | No |
Mechanical
| Diameter | 1.73 | Packaging | Bulk |
| Wire Gauge | 28-26 | Termination | Crimp |
| Contact Form | Machined | Contact Size | 20 |
| Contact Type | Signal | Contact Shape | Machined |
| Terminal Size | 20 | Connector Type | Connector D-Subminiature |
| Contact Finish | Gold Over Copper | Insert Material | 铜合金 |
| Contact Material | Copper Alloy | Package Quantity | Loose Piece |
| Primary Material | Copper Alloy | Termination Rows | 压接 |
| Termination Style | Crimp | 1st Contact Gender | Pin (Male) |
| Color - Connectors | 是 | Contact Tail Length | 20 |
| Contact Termination | Crimp | Dielectric Diameter | .072 mm [ 1.83 in ] |
| Insulation Diameter | 1.83 [.072] Max. | Length - Overall Pin | .325 |
| Contact Finish - Mating | 黑色、红色 | Contact Finish Thickness | 50 |
| Contact Material - Mating | Gold over Copper | Wire Gauge or Range - AWG | 0.08-0.15² [28-26] |
| Wire Gauge or Range - mm2 | 28 → 26 AWG | Contact Material - Plating | GoldoverCopper |
Product Info
| Mfr | .041 | Note | Contact is color coded. |
| Type | Signal | Gender | PIN |
| Series | 109 | Manufacturer | AMP |
| Product Type | Contact | Other Specifications | Wire/Cable |
| For Use With/Related Products | MIL-C-24308,MIL-C-39029 | ||
