206226-1

Business

Lead Time	28 Days	Tradename	CPC Series 3
Subcategory	Connector Circular	Product Category	Standard Circular Connector
Standard Package	Bulk	Factory Pack Quantity	100

RoHS	Lead free / RoHS Compliant	EU RoHS	Compliant
Tariff No	85369010	Compliance	No
Rad Hardened	No	Leadfree Defin	Not relevant for lead free process
RoHSELV Compliance	RoHS compliant, ELV compliant	Material Flammability Rating	UL 94V-0

Number of Channels

Color	Black	Sealed	No
Weight	0.036	Diameter	45.28 mm
Packaging	Bulk	Cable Exit	No
Shell Size	23	Orientation	Keyed
Shell Style	Plug	Termination	Crimp
Thread Size	1-3/8 - 18 UNEF-2A	Contact Form	7Signal
Contact Size	7 Power	Contact Type	7Power
Housing Color	Black	Mounting Type	Cable Mount
Angle of Throw	Straight	Connector Type	Plug for Male Contacts
Fastening Type	Threaded	Mounting Style	Free Hanging
Connector Style	Plug	Insertion Angle	:23-7
Material - Body	:Glass Filled Thermoplastic	Material Finish	:-
Contact Material	Copper	Housing Material	Thermoplastic
Length - Overall	41.78 mm	Primary Material	CircularPlasticConnector
Termination Style	Wire	1st Contact Gender	M
Color - Connectors	:Black	Mating Orientation	Keyed
Number of Contacts	7	Insulation Diameter	5.59 [0.220]
Number of Positions	7	Shell Size - Insert	All Plastic
Shell Material, Finish	Thermoplastic	1st Connector Mounting Type	:Cable
2nd Connector Mounting Feature	Reverse	Shell Size - Insert (Convert To)	23-7

Note	Contacts Not Provided	Type	CPC
Gender	PL	Series	Series 3
Features	ReverseGender	Preloaded	No
Arrangement	23-7	Manufacturer	Series3
Product Type	Connector	RF Family/Standard	206226
Other Specifications	Without	Application Specifics	Commercial
For Use With/Related Products	Pin Contacts
