206043-5

Business

Tradename	CPC Series 1	Product Category	Standard Circular Connector
Standard Package	Bulk	Factory Pack Quantity	100

RoHS	Lead free / RoHS Compliant	Compliance	No
Leadfree Defin	Not relevant for lead free process	RoHSELV Compliance	RoHS compliant, ELV compliant
UL Flammability Rating	UL 94V-0	Approval Agency Marking	否
Material Flammability Rating	UL 94V-0

Fluid Resistance	浸入	Number of Channels	14
Connector - Voltage Input	反向

Color	Black	Sealed	Yes
Outline	17	Packaging	Bulk
Body Color	黑色	Shell Size	17
Orientation	A	Shell Style	Receptacle
Termination	Crimp	Thread Size	1-3/8 - 18 UNEF-2A
Contact Size	16	Contact Type	Crimp
Housing Color	Black	Mounting Type	Cable Mount
Shell Plating	Elastomer	Angle of Throw	Straight
Connector Type	Receptacle for Female Contacts	Fastening Type	Threaded
Mounting Style	Free Hanging	Number of Pins	0
Shell Material	母端, 母端	Connector Style	Receptacle
Connector Usage	Threaded	Panel Thickness	0.125"
Housing Material	Thermoplastic	Package Quantity	100
Primary Material	CircularPlasticConnector	Termination Style	Wire
1st Contact Gender	Female	Mating Orientation	Keyed
Number of Contacts	14	Termination Finish	带有
Number of Positions	14	Shell Size - Insert	All Plastic
Mounting Hole Diameter	带有	Shell Material, Finish	Thermoplastic
2nd Connector Mounting Feature	Reverse

Note	Contacts Not Provided	Type	Sealed CPC
Gender	RCP	Series	Series 1
Features	ReverseGender	Key Type	A
Preloaded	No	Arrangement	17-14
Peripherals	Gray	Manufacturer	Series1
Product Type	Connector	Other Specifications	Without
Application Specifics	Commercial	For Use With/Related Products	Socket Contacts
