2-534206-6

Manufacturer	TE Connectivity Ltd.
Description	Conn Socket Strip SKT 52 POS 2.54mm Solder ST Thru-Hole Gang of Tubes .100 inch AMPMODU Receptacles CONN RCPT 52POS DL .100 VERT Headers & Wire Housings 52 MODII VRT DR CE 100/115 Conn Socket Strip SKT 52 POS 2.54mm Solder ST Thru-Hole Gang of Tubes Search Keywords:AMPMODU, board to board, NIC, Network Interface Cards, PC Cards, MIL-C-55032, MIL-C-24519, pcb connectors, wire to board, signal, 52 MODII VRT DR CE 100/115
Category	Connector SolutionsBoard to Board ConnectorsBoard-to-Board Connectors

对参数有疑问？问 AI 助手

Business

Tradename	AMPMODU	Product Category	Headers & Wire Housings
Standard Package	Rail / Tube

RoHS	Contains lead / RoHS non-compliant	MIL-C-55032	否
Standard Number	CSA LR7189, UL E28476	Material Flammability Rating	UL 94V-0

Resistance - Input	5000	Voltage - Rated AC	333
Current Rating (Max)	2 A

Color	Black	Pitch	2.54 mm
Height	5.03 mm [ .198 in ]	Packaging	Tube
Body Color	黑色	Row Spacing	0.100" (2.54mm)
Termination	Solder	Contact Type	Female Socket
Mounting Type	Through Hole	Connector Type	Receptacle
Contact Finish	Gold Over Nickel	Mounting Style	标准
Number of Rows	2	Pressure (PSI)	标准
Terminal Style	短点	Connector Usage	闭合入口, 顶部
Insert Material	磷青铜	Contact Material	Phosphor Bronze
Housing Material	Polycyclohexylenedimethylene Terephthalate (PCT)	Package Quantity	8
Panel Mount Type	通孔 - 焊接	Termination Style	Through Hole
Number of Contacts	52	Contact Tail Length	2.92
Number of Positions	52	Compatible Shell Size	与接头配合
Termination Post Length	2.92 mm [ .115 in ]	Contact Finish Thickness	30µin (0.76µm)

Note	TE 建议使用接合金或带双层电镀母端配件的双层电镀公端。, 为了获得最小接合柱长度，在最大触点尺寸上增加 .51 [.020]（不包含斜面上的柱引线）。	Type	Socket Strip
Gender	SKT	Series	AMPMODU MOD II
Sealable	否	Stackable	是
Product Type	Receptacles / Sockets - PCB	Assembly Configuration	板支座
Number of Positions Loaded	All
