2-520084-2

Business

Product	Faston Terminals	Product Category	Terminals
Standard Package	1,000	Factory Pack Quantity	1000

RoHS	RoHS Compliant	Tariff No	85369010
Rad Hardened	No	Leadfree Defin	Not relevant for lead free process
Approval Agency	:CSA, UL, VDE	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-2

Color	Red	Depth	6.98 mm
Width	2.8mm	Finish	Tin
Length	0.735in	Weight	0.005
Material	Brass	Packaging	Bulk
Tab Width	2.79 x 0.51 [.110 x .020], 3.18 x 0.51 [.125 x .020]	Thickness	0.5mm
Insulation	Insulated	Wire Gauge	22-18
Orientation	straight	Termination	Crimp
Body Material	Brass	Mounting Type	Free Hanging (In-Line)
Stud/Tab Size	:2.79mm	Tab Thickness	0.020" (0.51mm)
Terminal Type	Standard	Angle of Throw	Straight
Connector Type	Quick Disconnect Terminal	Contact Finish	Tin
Mounting Style	for cable	Plating - Body	Tin
Connector Style	Straight	Width - Overall	0.275"
Contact Material	Brass	Ferrule Material	insulated
Insulation Color	:Red	Length - Overall	0.735" (18.67mm)
Package Quantity	Loose Piece	Primary Material	QuickDisconnect
Insulation Height	Non-Insulation Support	Color - Connectors	:Red
Insulation Diameter	3.05 [.120] Max.	Insulation Material	Nylon
Material - Insulation	Yes	Wire Gauge or Range - AWG	:22AWG
Wire Gauge or Range - mm2	0.30-0.90Â² [22-18]	Contact Material - Plating	tinned
Diameter - Outside, Non-Expanded	:3.05mm
