2-1103101-3
| Manufacturer | |
| Description | HN.D.7.BU.C. 250 V Heavy Duty Connectors CONN INSERT FEMALE HN.D.7 SRS Heavy Duty Power Connectors FEM HOOD SIZE 1 7+PE HN.D.7 Connector Accessories Insert Female 7 POS Polycarbonate Loose Piece Connector Accessories Insert Female 7 POS Polycarbonate Loose Piece Product Highlights:HN.D.7 SeriesInsertProduct Size = 1Contact Type = Crimp TerminalInsert Style = SocketSearch Keywords:cabled power, DIN VDE 0110, DIN VDE 0627, DIN IEC707/VDE 0304, self extinguishing, non-flammable, European Metal Shell connector, rectangular industrial, input/output, box to box, Heavy Duty Connectors, Motorman, Motorman Hybrid, ELFA®, frequency converter, SurTec 650 INSERT, FEMALE, CRIMP, 7WAY Connector: HTS; female; HN.D; PIN:8; 7+PE; size 1; w/o terminals |
| Category |
Business
| Product Category | Heavy Duty Power Connectors | Standard Package | 10 |
| Factory Pack Quantity | 10 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | CSA, DIN VDE 0110, DIN VDE 0627, SEV, UL |
| Tariff No | 85369010 | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant / ELV compliant | Material Flammability Rating | UL94 V-0 |
Electrical
| Voltage Rating | 250V | Number of Poles | 7+PE |
| Current Rating (Max) | 10A | Voltage - Open Circuit | 250.0 |
| Connector - Voltage Input | w/o terminals | Current - Short Circuit (Isc) | 10.0 |
Mechanical
| Size | 1 | Color | Gray |
| Weight | 0.013 | Material | Glass-Filled Thermoplastic |
| Packaging | Bulk | Contact Type | HTS HN.D |
| Polarization | 3 | Mounting Type | crimped |
| Connector Type | Insert without Contacts | Mounting Style | for cable |
| Number of Rows | :3 | Package / Case | size 1 |
| Insertion Force | Female | Contact Material | :Copper |
| Housing Material | Polycarbonate (PC) | Package Quantity | Loose Piece |
| Size / Dimension | see | Termination Style | Crimp |
| 1st Contact Gender | :Socket | Number of Contacts | :7 |
| Contact Termination | :Crimp | Number of Positions | 7+Ground |
| Shell Size - Insert | :1 | Contact Layout, Typical | Crimp Terminal |
| 1st Connector Mounting Feature | 7+PE | ||
Product Info
| Spg | 10 | Note | Use with HN.D Series contacts |
| Gender | Female | Series | HN.D.7 |
| Manufacturer | HTS | Product Type | Insert |
| Adapter Series | HN.D | Number of Units | 1 |
| Other Specifications | Socket | ||
Environmental
| Operating Temperature | -40°C ~ 125°C | ||
