172163-1

Business

Product Category	Pin & Socket Connectors	Standard Package	Bulk
Factory Pack Quantity	500

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Leadfree Defin	Not relevant for lead free process	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-0

Color	Natural	Depth	23.7mm
Pitch	4.2 mm	Width	16mm
Height	16 mm	Length	30.4mm
Weight	0.001	Material	:Nylon
Lock Type	Positive Lock	Packaging	Bulk
Wire Gauge	16-30 AWG	Row Spacing	0.163" (4.14mm)
Contact Type	Male or Female	Pitch - Post	4.14 x 4.14 [.163 x .163]
Housing Color	Natural	Mounting Type	Straight
Connector Type	Receptacle	Fastening Type	Locking Ramp
Mounting Style	Panel	Number of Rows	3
Locking Feature	lock	Housing Material	Nylon
Length - Overall	30.4 mm	Package Quantity	One Piece Housing
Connector - Cable	plug/socket	Termination Style	Quick Connect
1st Contact Gender	Socket (Female)	Color - Connectors	:Clear
Number of Contacts	15	Contact Termination	Crimp
Number of Positions	15	Contact Layout, Typical	Matrix
Contact Finish Thickness	0.99 [0.039]	1st Connector Mounting Feature	3x5

Spg	100	Note	Contacts Not Provided
Type	Housing	Gender	RCP
Series	MATE-N-LOK	Product Type	Housing
Adapter Series	Mini Universal MATE-N-LOK	Number of Units	1
Module/Board Type	No	Number of Circuits	15
For Use With/Related Products	Wire-to-Board Connector
