170313-1
| Manufacturer | |
| Description | Contact PIN/SKT Crimp ST Cable Mount Loose Piece Drawer Connectors CONN HERMAPHRODITIC 24-20AWG Drawer,contact,hermaphrodtc,0.20-0.60mm2 Heavy Duty Power Connectors DRAWER CONNCONTACT Contact 24-20 AWG Contact PIN/SKT Crimp ST Cable Mount Loose Piece Product Highlights:ContactHermaphroditicWire Range = 0.20-0.60² [24-20] mm [AWG]Insulation Diameter = 1.50 - 1.95 mmLoose PieceSearch Keywords:NIC, Network Interface Cards, PC Cards, card edge, 1.0 mm Micro-Drawer, MPD, TE Connectivity Low Power Drawer 系列 公插至母座 压接接线端子, 压接, 镀金镀镍触点 DRAWER CONN.CONTACT |
| Category |
Business
| Other Names | 1703131 | Product Category | Heavy Duty Power Connectors |
| Standard Package | Bulk | Factory Pack Quantity | 1000 |
Compliance
| RoHS | Lead free / RoHS Compliant | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant, ELV compliant | ||
Electrical
| Voltage - Supply | 30 | Resistance - Input | 5000 |
| Voltage - Clamping | 2000 | Connector Impedance | 压接 |
| Current Rating (Max) | 7 | Current - Output High, Low | No |
Mechanical
| Width | .126 英寸, 3.2 mm | Height | 3.7 mm [ .1457 in ] |
| Length | 21 mm [ .8268 in ] | Packaging | Bulk |
| Cable Type | 绞线 | Wire Gauge | 20-24 AWG |
| Termination | Crimp | Contact Type | Signal |
| Pin or Socket | Non-Gendered | Cable Diameter | 0.5mm² |
| Connector Type | Connector Headers and PCB Receptacles | Contact Finish | Gold Over Nickel |
| Wire Duct Type | 直式 | Insert Material | 磷青铜 |
| Contact Material | Phosphor Bronze | Housing Material | 压接扣入式 |
| Material - Frame | 镍 | Package Quantity | Loose Piece |
| Termination Rows | 压接 | Termination Style | 插针/插座, 无极性 |
| Conductor Material | 铜 | Number of Contacts | 42 |
| Contact Termination | Crimp | Insulation Diameter | 1.50 â 1.95 [0.059 â 0.077] |
| Plating - Thickness | 金 | Contact Length - Post | 信号（数据）/电源 |
| Wire Gauge or Range - AWG | 20AWG | Wire Gauge or Range - mm2 | 0.20-0.60² [24-20] |
| Jacket (Insulation) Thickness | .3 µm, 11.81 µin | ||
Product Info
| Type | Signal | Gender | PIN/SKT |
| Series | Low Power Drawer | Product Type | Contact |
| Drawer Quantity | 小型电源 | ||
Environmental
| Operating Temperature | -30 – 105 | ||
