1658686-4

Business

Product Category	D-Sub Contacts	Standard Package	Bulk
Factory Pack Quantity	1000

RoHS	RoHS Compliant	Tariff No	85369010
Rad Hardened	No	Leadfree Defin	Not relevant for lead free process
RoHSELV Compliance	RoHS compliant, ELV compliant

Contact Resistance

:15mohm

Current Rating (Max)

:5A

Depth	1.91 mm	Pitch	Not Required mm
Weight	0.005	Plating	Gold
Material	Phosphor Bronze	Packaging	Bulk
Wire Gauge	28-22	Termination	Crimp
Contact Size	22	Contact Type	Signal
Mounting Type	Straight	Pin or Socket	Socket
Connector Type	Connector D-Subminiature	Contact Finish	Gold Over Nickel
Mounting Style	Cable	Contact Material	Phosphor Bronze
Housing Material	Not Required	Length - Overall	14.73 mm
Package Quantity	Loose Piece	Primary Material	Contact
Insulation Height	Yes	Termination Style	Crimp
1st Contact Gender	Socket (Female)	Number of Contacts	Not Required
Contact Tail Length	22	Contact Termination	Crimp Snap-In
Insulation Diameter	0.76 â 1.02 [0.030 â 0.040]	Plating - Thickness	Flash
Wire Gauge or Range - AWG	0.08 - 0.40 [28-22]	Wire Gauge or Range - mm2	:0.4mm²
Contact Material - Plating	GoldFlash	Diameter - Outside, Non-Expanded	:0.63mm

Note	For Hand Tool	Type	Stamped
Grade	Standard	Gender	SKT
Series	HD-20	Manufacturer	AMPLIMITEHDP-22Series
Product Type	Contact	Number of Ports	1 Port
For Use With/Related Products	:AMPLIMITE HDP-22 Connectors
